Panic [Guest][User][Power]; Dimmer [Guest][User][Power] - ETC sensor+ CEM+ Configuration Manual

R e c o r d P r e s e t s [User ]
The Record Presets menu allows a User to assign a preset number, and set the source for
levels, the fade time and playback priority and the room. If the preset number is already
recorded, you can record over it with the new settings, or if the preset is empty, you can
record these settings to that selected number.
S e t F a d e T i m e [ User ]
The Set Fade Time menu allows a User to update the fade time for a recorded preset.
S e t P r i o r i t y [ User ]
The Set Priority menu allows a User to update the priority for a recorded preset.
S e t P r e s e t N a m e [ User]
The Set Preset Name menu allows a User to update the name of a recorded preset. Names
are alphanumeric and can be up to 20 characters long (not all 20 characters will be visible
on the LCD).
S e t R o o m N a m e [ User]
The Set Room Name menu allows a User to set the name of a room.
M a x A c t i v e P r e s e t s [ User ]
The Max Active Presets menu allows a User to set the maximum number of active presets
for a selected room.
P a n i c [ G u e s t ] [ U s e r ] [ P o w e r ]
The Panic menu allows a Guest to activate and deactivate the Panic look and allows a
User to record and clear the Panic look.
A c t i v a t e P a n i c
The Activate Panic menu toggles between "Activate" and "Deactivate", depending on the
status of the Panic look.
R e c o r d P a n i c [User ]
The Record Panic menu allows you to record dimmers that currently have an output level
at the Master Level, or greater, to the Panic look. You can set the Master Level to anything
between 80% and 100%. When the Panic look is activated, the assigned dimmers will all
output at the Master Level. You can also choose to set all other dimmers to turn off when
panic is activated.
C l e a r P a n i c [User ]
The Clear Panic menu allows you to clear the current Panic settings.
C o n f i g u r e S w i t c h e s [ Power ]
The Configure Switches menu allows you to define the external switch action types
(maintained vs. momentary) and resting states (normally-open vs. normally-closed).
D i m m e r [ G u e s t ] [ U s e r ] [ P o w e r ]
The Dimmer menu allows Guest access to setting and releasing dimmer levels, and
S e t L e v e l s
The Set Levels menu allows you to set a dimmer or a range of dimmers to a specified level
2
Basic Navigation
allows User access to module setup items such as setting the module type, curve,
name, firing mode and properties. The Dimmer menu also allows a User to perform
a dimmer check.
10
