Dimmer Output Diagram

This diagram illustrates the relationship between min scale, max scale, curve, threshold, and preheat
for the dimmer output from a CEM3 channel.
Threshold(%)
With Preheat Disabled
Output goes to zero
26
Control Level
With Preheat Enabled
Output is at min scale
below threshold
100%
Max Scale Voltage
Min Scale Voltage
