  • Page 1 Document Number: 30635-000-002 PTC-1800 Product Reference Guide...
  • Page 2 Chapter 3 Configuring TN-3270/5250...
  • Page 3 PTC-1800 Product Reference Guide Document Number: 30635-000-002 Release Date: November 2000...
  • Page 4 The information in this manual is subject to change without notice. Symbol Technologies shall not be liable for technical or editorial omissions or mistakes in this manual. Nor shall it be liable for incidental or consequential damages resulting from the use of the information contained in this manual.

  • Page 5: Table Of Contents

    Chapter 3 - Scope of the manual..........7 Information ..................7 Included ..................7 Not included ................. 7 Related publications................ 7 Chapter 4 - Overview of the PTC-1800 ........9 Introduction ..................9 Description of PTC-1800 .............. 9 Accessories ..................9 Headset ..................9 Carrying case................
  • Page 6 Power management................. 25 Run mode..................25 Suspend mode ................25 Ship mode ..................26 Resume ..................26 Chapter 8 - Operating the PTC-1800........... 27 Turning on the PTC-1800 ............... 27 Turning off the PTC-1800 ............... 27 PTC-1800 Product Reference Guide...
  • Page 7 Deleting a call from the call list ..........55 Obtaining information about a call in the call list ..... 55 Clearing call lists ................. 57 Obtaining information about the telephone application.... 58 Exiting the telephone application ..........58 PTC-1800 Product Reference Guide...
  • Page 8 When to charge the bridge battery ..........69 Equipment required ..............69 Procedure..................69 Bridge battery support time ............70 Conditioning the bridge battery ............. 70 Replacing the bridge battery ............71 When to replace the bridge battery..........71 Replacement procedure ............... 71 PTC-1800 Product Reference Guide...
  • Page 9 Getting started ................77 Common solutions ................78 Getting help ..................81 Sources of information ..............81 Who to contact................81 Chapter 16 - Rebooting/Resetting the PTC-1800 ..... 83 Introduction ..................83 Rebooting the PTC-1800 ..............83 Overview ..................83 Procedure..................83 Resetting the PTC-1800 ..............
  • Page 10 Microprocessor ................86 Operating system ................. 86 Physical..................87 Storage..................87 Appendix B ..................89 Accessory part numbers..............89 Appendix C ..................91 Display icons and LED codes............91 Display icons ................91 LED codes..................92 PTC-1800 Product Reference Guide...

  • Page 11: Chapter 1 - Regulations

    This equipment has been tested and found to comply if any products not manufactured or with the limits for a Class B digital device, pursuant resold by Symbol are used with the to Part 15 of the Federal Communications PTC-1800 (e.g., another power Commission (FCC) rules.

  • Page 12: Spread Spectrum Radio Regulations

    The FCC ID is on a label on the back of the unit. DOC statement The PTC-1800's radio is also approved for use in Canada. The PTC-1800 uses a spread spectrum radio transceiver that qualifies for unlicensed use. The Canadian DOC ID is on a label on the back of the unit.

  • Page 13: Chapter 2 - Safety Information

    • To minimize risk of interference, pacemaker users SHOULD NOT carry the PTC-1800 next to the pacemaker. • Operation of the PTC-1800 with voice applications may produce an audible noise noticeable to hearing aid users.

  • Page 14: Disposal

    Recycling Do not throw away the PTC-1800 when it has reached the end of its useful life. Send it to an authorized Symbol service center for bridge battery removal and recycling before disposal.

  • Page 15: Internal Laser Scanner

    Internal laser scanner Internal laser scanner Safety compliance The PTC-1800's laser scanner is a Class II laser product. It emits a 1.0 mW beam of laser light from the output window. No Pre- released Version (2/25/00). maintenance is required to keep this product in compliance with U.S.
  • Page 16 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 17: Chapter 3 - Scope Of The Manual

    Included This manual provides information on the PTC-1800's parts, features, applications, and accessories. It also explains how to operate and maintain the PTC-1800. Not included This manual does not provide instructions on how to perform the tasks specific to your job in your organization.
  • Page 18 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 19: Chapter 4 - Overview Of The Ptc-1800

    See Chapters 9, 10, and 11 for more Depending on how it has been programmed, the information on each of the PTC-1800 may also be used to send and receive PTC-1800' s application options. telephone calls and VoiceAlert messages. Accessories Various accessories are available for use with the PTC-1800.
  • Page 20 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 21: Chapter 5 - Getting Started

    Follow the instructions below to unpack your notify your Symbol sales PTC-1800. representative. 1. Remove the PTC-1800 and other parts from the box. 2. Remove all packing material from the PTC-1800. Save the packaging in case the PTC-1800 is ever stored or shipped to Symbol for service.

  • Page 22: First-Time Use

    Connecting a ferrite bead to the AC or vehicle adapter To comply with Federal Communications Commission (FCC) Part 15, Class B regulations, a ferrite bead must be connected to the PTC-1800's AC or vehicle adapter before the adapter is used. A ferrite bead is shipped with the PTC-1800. Follow the instructions below to attach it properly.

  • Page 23: Chapter 6 - Parts

    The bridge battery keeps the unit’s memory intact while the battery pack is being replaced or if it runs out of power. DOC Hard disk drive The PTC-1800 contains an 8 MB hard disk drive identified as HARDDISK. Memory The PTC-1800 has two types of memory: •...

  • Page 24: Radio (Optional)

    Chapter 3 Configuring TN-3270/5250 Radio (optional) The PTC-1800 can be equipped with a local area network spread spectrum radio. Spread spectrum radios allow the PTC-1800 to communicate interactively in realtime with other radio devices on a radio-based local area network.
  • Page 25 External components 1. Status LED 8. Antenna 2. Speaker 3. Display screen 7. Push-to-talk button (for VoiceAlert application) 4. Keypad 6. Microphone 5. Headset jack Figure 1. Parts of the PTC-1800 (front view) PTC-1800 Product Reference Guide...
  • Page 26 Chapter 3 Configuring TN-3270/5250 Table 1. Parts of the PTC-1800 (front view) Name Description Status LED Glows or blinks to indicate the status of the PTC-1800, the laser scanner, and the recharging process. (See Appendix C for an interpretation of the Status LED.)
  • Page 27 Table 2. The PTC-1800 keypad* Name Description Compass key Moves the cursor on the PTC-1800’s display screen in one of four directions: up, down, left, or right. (These will be referred to from here on as the Up, Down, Left, and Right arrow keys.)
  • Page 28 *The functions of the PTC-1800’s keys vary depending on the active application. Table provides a description of the general functionality of the PTC-1800’s keys. See the "Key funcitons" section in Chapter 10 for the funcitons of the PTC-1800’s keys when the telephone application is active.
  • Page 29 1. Charger jack 1. Charger jack 2. Battery pack release button 3. Battery pack 4. Charger contacts 8. Laser scanner 7. Infrared port 9. Reset button Figure 3. Parts of the PTC-1800 (left side, top, and back views) PTC-1800 Product Reference Guide...
  • Page 30 (Refer to Chapter 12 for instruction son replacing the battery pack.) Battery pack The PTC-1800 is powered by a standard or extended-life lithium-ion battery pack. Caution! Never leave the PTC-1800 without the battery pack installed. Removal of the pack for extended periods will drain the bridge battery (even with the unit suspended.)
  • Page 31 Description Laser scanner Scans bar codes. (See Chapter 9 for details.) Reset button Press to place unit in ship mode. Press (behind the On/Off key to perform a cold boot battery pack) after resetting the unit. PTC-1800 Product Reference Guide...
  • Page 32 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 33: Chapter 7 - Features

    The backlight may be reactivated by pressing any of the PTC-1800's keys. Clock The PTC-1800's built-in clock keeps track of the date (month, day, year, and day of the week) and the time (hours, minutes and seconds). The clock operates continuously.

  • Page 34: Display Contrast

    Display contrast Each press of the Left or Right arrow The contrast of the PTC-1800's display screen can be key progressively decreases or in- increased or decreased as follows. creases, respectively, the contrast of 1.

  • Page 35: Low-Battery Warning

    Low-battery warning Low-battery warning The PTC-1800 warns you when the battery pack or the bridge battery is running out of power. Table 4 shows the low-battery warnings and the actions you should take to correct them. Table 4. Low-battery warning...

  • Page 36: Ship Mode

    Resume If the PTC-1800 is suspended, pressing the On/Off key or one of the Scan keys turns the PTC-1800 back on and returns you to the point at which you left the application.

  • Page 37: Chapter 8 - Operating The Ptc-1800

    If the PTC-1800 is in suspend, you can wake it by pressing the On/Off key or one of the Scan keys. If the PTC-1800 is in ship mode, you cold boot it by pressing the On/Off key. Turning off the PTC-1800 Refer to the “Power management”...
  • Page 38 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 39: Chapter 9 - Data Application

    Overview Your organization has developed an application to meet its data collection needs. This application allows the PTC-1800 to collect, store, and transmit data to a host device. Using the application Follow the instructions below to begin using the data application.

  • Page 40: Via The Keyboard

    A bar code is a series of vertical bars Data can also be entered with the PTC-1800's laser and spaces used to encode scanner. When you scan a 1D bar code, the PTC-1800 information in a machine-readable is programmed to read, while the PTC-1800 and form.

  • Page 41: Via An Optional Internal Radio

    Up to 22 in./55.9 cm 55 MIL Up to 29 in./73.7 cm The Status LED glows amber when 2. Press one of the PTC-1800's Scan keys to start the scanner is scanning a bar code. scanning. The PTC-1800 beeps if the scan is 3.

  • Page 42: Communicating Data

    After collecting the data, the PTC-1800 can transmit it to a host device for processing or for sending it to a printer. The PTC-1800 can transmit data via its IrDA port or through its optional internal LAN radio. Using the IrDA port...

  • Page 43: Chapter 10 - Telephone Application

    Chapter Telephone application Overview The telephone application uses voice-over-IP technology to allow users to send and receive telephone calls via the PTC-1800 to/from the following devices: • Other PTC-1800s on the same wireless LAN, • Other H.323 devices on the same wireless LAN, •...

  • Page 44: Key Functions

    Chapter 3 Configuring TN-3270/5250 Key functions The function of the PTC-1800's keys varies with the active application. Table 6 describes the functions of the PTC-1800's keys when the telephone application is activated. Table 6. Key functions of the telephone application...

  • Page 45: Accessing The Telephone Application

    Press the Phone key to activate the telephone application. The Home screen displays. The Home screen is divided into four sections, as shown in Figure 4: Combo box Top group box Bottom group box Status bar Figure 4. The Home Screen PTC-1800 Product Reference Guide...
  • Page 46 Dialed calls Pressing the Up arrow key opens the list dialed calls list, from which you may select a previously dialed number to call. PTC-1800 Product Reference Guide...
  • Page 47 The second line of the top group ber/address box shows the telephone number, IP address, E.164 address, or host name of the call on Line 2. Display message Displays information about the caller on Line 1 (e.g., dept. name). PTC-1800 Product Reference Guide...
  • Page 48 Component Location Function of Soft Left side of status bar (e.g., Key 1 Menu) Active application Middle of status bar (e.g., Phone) Function of Soft Right side of status bar Key 2 PTC-1800 Product Reference Guide...

  • Page 49: Menu Structure

    You can create a telephone directory to access easily the telephone numbers of people you call frequently. Each directory entry, which is stored in the PTC-1800, contains the person's first and last name as well as his/her telephone number, IP address, E.164 address, or host name.
  • Page 50 Chapter 3 Configuring TN-3270/5250 Adding a telephone directory entry Follow the instructions below to create a telephone directory or to add an entry to the PTC-1800's existing telephone directory. 1. At the Home screen, press the SK1 key. The Main Menu displays (see Figure 6).
  • Page 51 (see Figure 8). Figure 8. Telephone Directory Screen 10. Press the Down arrow key to select the type of number you are going to enter for this entry (i.e., telephone number, host name, or IP address). PTC-1800 Product Reference Guide...
  • Page 52 Repeat the steps of this procedure if 17. Press the SK1 key twice to highlight the Done you wish to add additional entries to button. the PTC-1800' s telephone directory. 18. Press the Send key. PTC-1800 Product Reference Guide...
  • Page 53 7. Press the SK1 key to move to the Sort field. 8. Press the Down arrow key to select how names are listed in the telephone directory (i.e., alpha- betically by name or according to frequency of use). 9. Press the Send key. PTC-1800 Product Reference Guide...
  • Page 54 6. Press the Down arrow key to highlight either Yes or No. 7. Press the Send key. If you selected Yes, the entry will be deleted from the telephone directory. If you selected No, the entry will not be removed from the telephone directory. PTC-1800 Product Reference Guide...
  • Page 55 Setting up the telephone a telephone directory entry Obtaining information about Follow the instructions below to obtain information about any entry in the PTC-1800's telephone directory. 1. At the Home screen, press the Down arrow key to display the telephone directory.

  • Page 56: Setting The Telephone Alert

    6. Press the End key to exit the Information screen and return to the Home screen. Setting the telephone alert The PTC-1800 can be configured to ring and/or vibrate when it receives an incoming call. Follow the instructions below to specify how you want to be notified.
  • Page 57 Speaker box Description The PTC will ring when it receives an þ incoming call. The PTC will not ring when it receives ¨ an incoming call. 10. Press the SK1 key to move to the Vibrate checkbox. PTC-1800 Product Reference Guide...

  • Page 58: Locking The Keyboard

    5. Press the Send key. The keyboard is now locked. Unlocking the keyboard Follow the instructions below to unlock the PTC- 1800's keyboard. 1. Press one of the PTC-1800's keys. The following message displays: Keys Locked Press 'Unlock' then '5'...

  • Page 59: Turning On The Auto Answer Feature

    3. Press the 5 key. The keyboard is now unlocked. Turning on the Auto Answer feature If you are talking on Line 1 and a call Follow the instructions below to set the PTC-1800 to comes in while the Auto Answer answer incoming calls automatically (without you feature is on, a checkmark appears having to press the Send key).

  • Page 60: Initializing Keypad Tones

    Chapter 3 Configuring TN-3270/5250 Initializing keypad tones Follow the instructions below to set the PTC-1800 to generate a tone when its keys are pressed. 1. At the Home screen, press the SK1 key. The Main Menu displays (see Figure 6).
  • Page 61 The user name assigned to your PTC- 1800. Display A short message corresponding to the Message assigned user(s) of the PTC-1800 (e.g., the name of the user’s department). 6. Press the End key to exit the User Identification screen and return to the Home screen.

  • Page 62: Operating The Telephone

    Down Arrow key to select a number from the list that you want to call. 3. Press the Send key. 4. Speak into the microphone on the PTC-1800 or on an attached headset. While a call is in progress, the Call 5.

  • Page 63: Receiving An Incoming Call

    Operating the telephone Receiving an incoming call The PTC-1800 will ring and/or vibrate (depending on how your PTC-1800 was configured) to alert you to an incoming call. The display will also provide caller ID functions, such as the caller's name and telephone number.

  • Page 64: Viewing Call Lists

    Saving an entry in a call list to the telephone directory Follow the instructions below to save a dialed, received, or missed call to the PTC-1800's telephone directory. 1. Follow the instructions in the “Viewing call lists”...

  • Page 65: Deleting A Call From The Call List

    54 to access the Dialed Calls screen, Received Calls screen, or Missed Calls screen. 2. Press the Up or Down arrow key to select the entry in the list that you want to obtain information about. PTC-1800 Product Reference Guide...
  • Page 66 The date and time of the last call to/ from this number. Call Count The number of times a call has been placed to this number, received from this number, or missed. Duration The length of the call. PTC-1800 Product Reference Guide...

  • Page 67: Clearing Call Lists

    Clears all calls from the Dialed Calls screen. Received Clears all calls from the Received Calls Calls screen. Missed Calls Clears all calls from the Missed Calls screen. To exit without change. 7. Press the Send key. PTC-1800 Product Reference Guide...

  • Page 68: Obtaining Information About The Telephone Application

    2. Press the Down arrow key until About is highlighted. 3. Press the Send key. The About PTC-1800 screen displays. 4. Press the End key to exit the About PTC-1800 screen. Exiting the telephone application Follow the instructions below to exit the PTC-1800's telephone application.

  • Page 69: Chapter 11 - Voicealert Application

    Chapter VoiceAlert application Overview The VoiceAlert application uses voice-over-IP technology to allow the PTC-1800's user to talk and listen to other users within specified VoiceAlert groups. The PTC-1800s in each group must be properly configured and running the VoiceAlert application. Only configured members of the group...

  • Page 70: Selecting The Type Of Voicealert Notification

    Max and Min. Selecting the type of VoiceAlert notification This section allows you to select how the PTC-1800 will alert you to an incoming broadcast message. Audible alert In the bottom left-hand corner of the VoiceAlert screen is a Mute checkbox.

  • Page 71: Operating The Voicealert Application

    In the bottom right-hand corner of the Voice-Alert screen is a Vib checkbox. Press the SK2 key to check or uncheck this box. Vib box Description The PTC-1800 will vibrate to alert þ you to an incoming broadcast mes- sage. The PTC-1800 will not vibrate when ¨...

  • Page 72: Receiving A Broadcast Message

    Receiving a broadcast message The PTC-1800 will beep and/or vibrate (depending on how your PTC-1800 was configured) to alert you to an incoming broadcast message. Place your ear near the PTC-1800's speaker and listen to the incoming message.

  • Page 73: Chapter 12 - Maintaining The Battery Pack

    ! You must suspend the PTC-1800 1. Suspend the PTC-1800. before replacing its battery pack. 2. Turn the PTC-1800 over so the back is facing you. ! Do not leave the PTC-1800 without 3. Press the battery pack release button as you slide a battery pack installed.

  • Page 74: Installing A New Battery Pack

    (Appendix C) appears. recharged. Charging time The amount of time it takes for the PTC-1800's built- in charger to recharge a battery pack depends on several factors: •...

  • Page 75: Charging Guidelines

    Use only a Symbol battery charger designed for use with your PTC-1800's battery pack. Charging the battery pack Via the AC or cigarette lighter adapter Follow the instructions below to charge the PTC-1800's battery pack using an AC or cigarette lighter adapter. PTC-1800 Product Reference Guide...

  • Page 76: Battery Pack Life

    PTC-1800 or the cigarette lighter adapter from the vehicle's cigarette lighter socket and then from the PTC-1800. Via the Model 1822 charger To charge the PTC-1800's battery pack via the Model 1822 charger, follow the instructions provided with the charger. Battery pack life...

  • Page 77: Storing Spare Battery Packs

    Store your lithium-ion batteries in a cool, dry, well- batteries in temperatures above 104 ventilated, and weatherproof location where the F° (40 C°) or in environments with a temperature is –4 to 104° (–20 to 40 C°). relative humidity of over 95%. PTC-1800 Product Reference Guide...
  • Page 78 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 79: Chapter 13 - Maintaining The Bridge Battery

    Low Bridge icon (Appendix C) displays on the PTC-1800's screen, and whenever the main battery pack has been left out of the PTC-1800 for an extended period of time. Equipment required The following equipment is required to recharge the PTC-1800's bridge battery: •...

  • Page 80: Bridge Battery Support Time

    This means that even if the bridge battery appears to be fully charged, it may not be able to back up the contents of the PTC-1800's memory if the main battery pack is removed before the PTC-1800 is placed into suspend mode.

  • Page 81: Replacing The Bridge Battery

    Replacing the bridge battery 6. Charge the PTC-1800 for at least 5 hours. The bridge battery has now been conditioned and is good for another month of service. Replacing the bridge battery When to replace the bridge battery Symbol recommends that the PTC-1800's bridge battery be replaced every 3–5 years under normal...
  • Page 82 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 83: Chapter 14 - Maintaining The Ptc-1800

    • Avoid dropping the PTC-1800 or knocking it against a hard surface. • Carry the PTC-1800 in a holster or carrying case to protect it. • If you have stored the PTC-1800 or its battery pack in below-freezing temperatures for more than 1 hour, the battery pack may be too cold to charge.

  • Page 84: Storing/Shipping The Ptc-1800

    Do not store the PTC-1800 in temperatures below –4 F° (–20 C°) or above 104 F° (40 C°). • Do not store the PTC-1800 in a damp or humid environment. Procedure 1. Transfer any data stored in the PTC-1800 to a host computer or another PTC-1800.

  • Page 85: Cleaning The Ptc-1800

    Isopropyl alcohol or a battery contact cleaner. Cleaning the PTC-1800 ! Do not soak the cloth and do not To clean the PTC-1800, slightly moisten a soft, clean, spray or pour cleaning liquids lint-free cloth with a mild, nonabrasive liquid cleaner directly onto the PTC-1800.

  • Page 86: Disposing Of The Ptc-1800

    Chapter 3 Configuring TN-3270/5250 Disposing of the PTC-1800 When your PTC-1800 has reached the end of its useful life, do not throw it away. Send it to an authorized Symbol service center for bridge battery removal and recycling before its disposal.

  • Page 87: Chapter 15 - Troubleshooting

    Does the Status LED glow? Does it stay on or blink? See Appendix C for an explanation of the PTC-1800's Status LED codes. • Do any icons appear on the PTC-1800's display screen? See Appendix C for an explanation of the display icons. •...

  • Page 88: Common Solutions

    PTC-1800 serviced. The PTC-1800’s screen is • Wait until the PTC-1800 warms up to room temperature if it has been stored or used in slow to refresh. the cold. The battery pack runs •...
  • Page 89 PTC serviced. • Check that the radio type matches your access point radio system. • Check the antenna. • Validate that the telephones are all using the same vocoder (e.g. G.711). PTC-1800 Product Reference Guide...
  • Page 90 • Make sure the bar-code label you are trying to scan is one of the bar-code types that your PTC-1800 has been programmed to recognize. • The PTC-1800’s application program may not support scanned data at this particular field.

  • Page 91: Getting Help

    Microsoft manuals. • Review the documentation for your application. Who to contact If reviewing the above sources of information does not improve the PTC-1800's performance, notify the following Symbol personnel: • Your Symbol service representative. • The Symbol Customer Support Center at 1-800-653-5350.
  • Page 92 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 93: Chapter 16 - Rebooting/Resetting The Ptc-1800

    4. Press the Down arrow key to highlight either Yes or No. 5. Press the Send key. If you selected Yes, wait for the PTC-1800 to reboot. If you selected No, the PTC-1800 will return to the operating system. PTC-1800 Product Reference Guide...

  • Page 94: Resetting The Ptc-1800

    ! Never reset the PTC-1800 unless If rebooting is not effective, you may have to reset the absolutely necessary. Resetting the PTC-1800. When the PTC-1800 reboots after a reset, PTC-1800 erases all programs and it returns you to the operating system.

  • Page 95: Specifications

    1/8 VGA, 160 x 240 pixels Backlight Electro-luminescent (EL) panel Electrical Battery pack Standard: 1450-mAhr @ 3.7 VDC lithium-ion Extended-life: 3200-mAhr @ 3.7 VDC lithium-ion AC adapter Input: 100–240 VAC/50–60 Hz Output: 12 VDC @ 1.2 A PTC-1800 Product Reference Guide...

  • Page 96: Environmental

    Operating humidity 0 to 95% noncondensing @ 104 F (40 C°) Shock 4-ft/1.2-m drop to concrete Note: If the PTC-1800's battery pack dislodges, the connection to the LAN network will have to be re-established. Altitude Operating: Up to 10,000 ft/3,048 m...

  • Page 97: Physical

    2.6 in/6.6 cm Thickness 1.2 in/3 cm Weight 12 to 13 oz/.34 to .37 kg (with standard battery pack); 14 to 15 oz/.4 to .43 kg (with extended-life battery pack) Storage Hard disk drive Internal 8-MB solid-state drive PTC-1800 Product Reference Guide...
  • Page 98 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 99: Accessory Part Numbers

    Accessory part numbers Appendix Accessory part numbers Table 13 contains part numbers for ordering PTC-1800 accessories. Contact your Symbol sales representative or visit www.symbol.com to order any of the following parts. Table 13. Accessory part numbers Item Part number Hardware AC Adapter (12 VDC, 1.2 A)
  • Page 100 Chapter 3 Configuring TN-3270/5250 PTC-1800 Product Reference Guide...

  • Page 101: Display Icons And Led Codes

    Icon Name Description Low Batt The battery pack is low; recharge it. Low Bridge The bridge battery is low; recharge the battery pack. Out of Range The radio is out of range of an access point. PTC-1800 Product Reference Guide...

  • Page 102: Led Codes

    Chapter 3 Configuring TN-3270/5250 LED codes Table 15 interprets the codes for the PTC-1800's Status light-emitting diode (LED). Table 15. LED codes Status LED Explanation Blinking green The PTC-1800’s battery pack is being charged. Green The PTC-1800’s battery pack has been charged (to a 90% or greater capacity).
  • Page 103 , 91 Display icons and LED codes , 70 Bridge battery support time , 4, 63 Disposal , 76 Disposing of the PTC-1800 , 13 DOC Hard disk drive Carrying case , 1, 2 DOC statement , 65 Charging guidelines...
  • Page 104 , 52 Operating the telephone , 9, 32, 83 Introduction Operating the VoiceAlert , 61 application , 29, 33, 59, 63, 69, Overview , 34 Key functions 83, 84 Overview of the PTC-1800 , 86 Laser scanner PTC-1800 Product Reference Guide...
  • Page 105 , 26 Resume Turning off the Auto Answer , 25 Run mode , 49 feature , 27 Turning off the PTC-1800 Turning on the Auto Answer , 4, 5 Safety compliance , 49 feature Safety information , 27 Turning on the PTC-1800...
  • Page 106 , 24 VoiceAlert , 24, 59 VoiceAlert application Warning label When to charge the battery pack When to charge the bridge , 69 battery When to replace the bridge , 71 battery , 81 Who to contact PTC-1800 Product Reference Guide...
