  • Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.

  • Page 3: Table Of Contents

    Q u i c k R e f e r e n c e Introduction Congratulations on your purchase of Symbol Technologies’ PDT ® 8000 Series Terminal with Windows Mobile 2003 Software for Pocket PCs! Its unique combination of features make this product superior for use in a wide range of applications.

  • Page 4: Accessories

    Regulatory Information on page 31 • Service Information on backcover. The PDT 8000 Series with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide (p/n 72-67082-xx) details the applications available for the terminal. For the latest version of this guide go to: http://www.symbol.com/manuals.

  • Page 5: Parts Of The Terminal

    Q u i c k R e f e r e n c e • Four-Slot USB-to-Ethernet Cradle (p/n CRD8000-4000E) • Holster (p/n 11-57530-02). Parts of the Terminal Front View Scan Charge Microphone TFT LCD (color) Power Button Speaker Top View 1-D Exit Audio Jack Window...
  • Page 6 P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s Parts of the Terminal (continued) Back View...

  • Page 7: Inserting A Compact Flash Storage Card

    Q u i c k R e f e r e n c e Inserting a Compact Flash Storage Card The PDT 8000 has a slot for a compact flash storage card which includes a compartment door that prevents the card from coming out if the PDT 8000 is dropped.

  • Page 8: Installing Batteries

    P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s Installing Batteries 1.

  • Page 9: Charging The Battery

    Q u i c k R e f e r e n c e Charging the Battery Charging the Main Battery and Memory Backup Battery Before using your terminal for the first time, charge the lithium-ion battery in the terminal for approximately four hours, using the Serial Charging Cable or any other appropriate accessory.
  • Page 10 P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s The terminal charge LED blinks amber to indicate that the terminal battery is charging and turns solid amber when charging is...

  • Page 11: Starting The Terminal

    Troubleshooting on page Power Button As the terminal initializes its unique Flash File system, the Symbol splash screen displays for about 60 seconds. When the Welcome screen appears, tap anywhere on the screen to continue to the Align screen. Note that these screens also appear every time you perform a hard reset.

  • Page 12: Adjusting The Backlight

    P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s 3.

  • Page 13: Using A Headset

    To use the headset, plug the headset jack into the audio connector on the top of the terminal. For more detailed headset information, refer to the PDT 8000 Series with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide. Using the Keyboard Note: Key functions can be changed by an application.
  • Page 14 P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s Right Page-up &...

  • Page 15: Using The Stylus

    Q u i c k R e f e r e n c e Action App Key 3 Launches application assigned to Button 3. Refer to the PDT 8000 Series with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide (p/n 72-67082-xx) for more in- formation on assigning applications to button.

  • Page 16: Today Screen

    P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s Today Screen When you turn on your terminal for the first time each day (or after...

  • Page 17: Navigation Bar And Command Bar

    Q u i c k R e f e r e n c e Navigation Bar and Command Bar The navigation bar at the top of the screen displays the active program and current time, and allows you to switch to programs and close screens.

  • Page 18: Input Methods

    P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s Input Methods Enter information in any program by typing with the keyboard, or...
  • Page 19 Q u i c k R e f e r e n c e Using the Block Recognizer 1. Tap the arrow next to the Input Panel button, then Block Rec- ognizer. 2. Write a letter in the left side of the box, or a number in the right side, using special character strokes.
  • Page 20 P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s Using the Transcriber 1.

  • Page 21: Scanning With The Terminal

    Scanning with the Terminal The terminal has an integrated scanner which collects data by scanning bar codes. Refer to the PDT 8000 Series with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide (p/n 72-67082-xx) for information on configuring your terminal for scanning.

  • Page 22: Host Communications

    Spectrum24 wireless LAN. For more information on setting up and performing communications with your terminal, refer to the PDT 8000 Series with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide (p/n 72-67082-xx). Using the Accessories The terminal can communicate with a host computer using the...

  • Page 23: Led Indicators

    R e f e r e n c e Cradle, the Single-Slot Modem Cradle, the Four-Slot USB-to- Ethernet Cradle, or the Snap-On-Modem. For more information, see the communication instructions in the PDT 8000 Series with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide (p/n 72-67082-xx).

  • Page 24: Maintaining The Terminal

    Using the holster An optional holster, to store the terminal when not in use, is available through Symbol. Hook the holster on to your belt and insert the terminal, with the display facing you, as shown.

  • Page 25: Troubleshooting

    Communication Perform setup as described in the software was incor- PDT 8000 Series with Windows Mo- rectly installed or bile 2003 Software for Pocket PCs configured. Product Reference Guide (p/n 72- 67082-xx). No sound is audi-...
  • Page 26 See the PDT 8000 Series with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide (p/n 72- 67082-xx) for information about how to write character strokes.
  • Page 27 Q u i c k R e f e r e n c e Problem Cause Solution A message ap- Too many files Delete unused memos and records. pears stating that stored on the termi- You can save these records on your your terminal’s nal.
  • Page 28 See your Sys- scan input. tem Administrator. Unreadable bar Ensure the symbol is not defaced. code. Distance between Ensure you are within proper scanning exit window and bar range. code is incorrect.
  • Page 29 Q u i c k R e f e r e n c e END-USER LICENSE AGREEMENT MICROSOFT WINDOWS FOR POCKET PC DATA EXCHANGE COMPONENT: MICROSOFT ACTIVESYNC, VERSION 3.1 IMPORTANT-READ CAREFULLY: This End-User License Agreement (“EULA”) is a legal agreement between you (either an individual or a single entity) and the manufacturer (“Manufacturer”) of the special purpose computing device (“SYSTEM”) with which you acquired the Microsoft software product(s) identified above (“SOFTWARE”).
  • Page 30 P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s access, and interact with the SYSTEM, and (ii) the EULA is between Manufac- turer (as defined above) and the end user-not between the PC Manufacturer...
  • Page 31 Q u i c k R e f e r e n c e or other means, and labeled “For Upgrade Purposes Only” or “For Recovery Purposes Only”, you may (i) install and use one copy of such component(s) on the computer(s) you use to exchange data with the SYSTEM as a replacement copy for the existing Desktop Software component(s).

  • Page 32: Battery Information

    Replace the battery when a significant loss of run time is detected. Standard warranty period for all Symbol batteries is 30 days, regardless if the battery was purchased separately or included as part of the mobile computer or bar code scanner.

  • Page 33: Regulatory Information

    R e f e r e n c e Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment.
  • Page 34 The use of these accessories that do not satisfy these requirements may not comply with FCC RF exposure compliance requirements, and should be avoided. Laser Devices Symbol devices using lasers comply with US 21CFR1040.10, and IEC825- 1:1993, EN60825-1:1994+A11:1996. The laser classification is marked on one of the labels on the device.
  • Page 35 LE FAISEAU APPARIEL À LASER DE CLASSE 2 LASER LIGHT- DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT 630-680nm, 1mW S/N: ######### FCC ID: ############# Made in XXXXX MOD: PDT8000-XXXXXXXX Symbol Technologies Inc. Holtsville, New York 11742 MONTH, 2002...
  • Page 36 P D T 8 0 0 0 S e r i e s w i t h W i n d o w s M o b i l e 2 0 0 3 f o r P o c k e t P C s Laser Labels In accordance with Clause 5, IEC 825 and EN60825, the following information is...
  • Page 37 R e f e r e n c e Power Supply Note: Use only a Symbol-approved power supply 50-14001-005 output rated 15Vdc and minimum 2.5A. The power supply is certified to EN60950 with SELV outputs. Use of alternative power supply will invalidate any approval given to this device and may be dangerous.
  • Page 38 Symbol Declaration of Conformity (DoC) for details at http://www2.symbol.com/ doc/. Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directives 1999/5/EC, 89/ 336/EEC and 73/23/EEC. Declaration of Conformities may be obtained from http:// www2.symbol.com/doc/.
  • Page 39 Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which...
  • Page 40 +1-954-255-2610 Outside US Europe/Mid-East Contact local distributor or call Distributor Operations +44 118 945 7360 For the latest version of this guide go to: http://www.symbol.com/manuals. 72-67080-01 Revision A — January 2004 Symbol Technologies, Inc. One Symbol Plaza, Holtsville, N.Y. 11742-1300...
