3 Components and Power Supply
B

3.1.4 Upper Panel

The following figure shows the aspect of the upper panel:
Upper panel
Fig. 6:
The upper casing elements are as follows.
Upper casing elements table
Items
A, B, C, D

3.2 Assembly

3.2.1 Installing a DIN rail mount accessory

The Regesta Lite AU packaging includes a DIN rail mount kit to which the device can be connected (allowing for
several positions).
The kit contains 2 screws to adjust the rail mount to the underside of the device. There are a set of holes on the un-
derside that allow you to place the DIN rail mount in two different positions:
8
Platform where the label containing product information is placed. This label con-
tains information on the device model, MAC, serial number, etc.
Description
Screws that allow you to disassemble the router's upper casing.
Teldat S.A.
Regesta Lite AU
