Cut Width

The movement range of the blade in Cross Cut operation is from the outer edge of the leftmost grit roller to the
outer edge of the rightmost grit roller. The media should be set within this range.

Manually cross-cut

Cross-cut at the current tool carriage position.
When the [CROSS CUT(execute)] is selected, you can separate the roll media at any position by cross-cutting it
manually after feeding it with the POSITION (
When the [FEED&CROSS CUT(exe)] is selected, the roll media is cross-cut after feeding 1 page. When specifying
1 page, set a value obtained by adding 20 mm and the value set in the "SPACE REAR" to the value set in the
"PAGE LENGTH".
Operation
1
Press the [CROSS CUT] key in the default screen.
CROSS CUT screen is displayed.
2
Press the [1] key (FEED&CROSS CUT(exe)), or the [2] key
(FEED&CROSS CUT(exe)) to select the mode.
Cross-cut the media.
Grit roller
) key.
Supplement
It will return to default screen without performing
the Cross Cut when you press the [ESC] key
(CANCEL).
7-26
