Appendix B Radio Information

B.1 RF LTE specifications
The LTE equipment model with the MC7304 module provides LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA,
GSM, GPRS and EDGE network connectivity over several radio frequency bands, in accordance with 3GPP stand-
ards.
This product is supplied without any antennas. The operator must make sure that the antennas of his/her picking
comply with the local regulations.
Technology: LTE
Bands
Band 1
Band 3
Band 7
Band 8
Band 20
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+
Bands
Band 1
Band 2
Band 5
Band 8
Technology: GSM / GPRS / EDGE
Bands
GSM 850 (850 MHz)
Teldat H2 RAIL Lite
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Tx: 832–862 MHz
Rx: 791–821 MHz
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1850–1910 MHz
Rx: 1930–1990 MHz
Tx: 824–849 MHz
Rx: 869–894 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Frequencies
Tx: 824–849 MHz
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+22 dBm ± 1 dB
+23 dBm ± 1 dB
+23 dBm ± 1 dB
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+23 dBm ± 1 dB
+23 dBm ± 1 dB
Conducted Transmit Power
+32 dBm ± 1 dB
