WLAN/WiFi Connector (male)

DSL Connector

RJ11 DSL

USB Connector

USB Type A

Configuration Connector

RJ45 CONFIGURATION
T 8. WLAN/W
ABLE
RJ11 PIN
T 9. DSL C
ABLE
T 10. USB C
ABLE
RJ45 PIN
T 11. C
ABLE ONFIGURATION CONNECTOR
TELDAT V
– Installation Manual
I - 27
PIN ANT
Internal RF in/out
External
GND
F C
I I ONNECTOR
DSL
1 Joined to 2
2
Line
3 Line
4 Joined to 3
ONNECTOR
PIN USB
1
VCC
2 DATA-
3
DATA+
4 GND
Shell
Shield
ONNECTOR
CONF
1 --
2 RxD
3 GND
4 --
5 --
6
GND
7 TxD
8
--
