Selecting an Input

• Press and release the desired PROGRAM or PREVIEW input selection button. The button
lights and the selected input displays on the program or preview monitor.
Press the MUTE or FREEZE buttons to mute or freeze the PROGRAM or PREVIEW output
•
video.

Switching the Preview Output to the Program Output

1. Press and release a preview input button.
2. Press and release one of the EFFECTS buttons.
• CUT — This effect does not need to be configured. When used, the image instantly
swaps between the preview output and the program output without any effect.
• DISSOLVE — The previous program output fades out while the image from the
preview output fades into the program output using the user-defined duration. To
configure, see
• WIPE — The image in the preview output "unrolls" over the top of the program
output using the user-defined duration and direction. To configure, see
page 21.
• PIP — The image in the preview output appears in the program output as a
picture-in-picture window using a dissolve effect and the user-defined duration. To
recall a PIP preset, see
• VIDEO KEY — Video on the preview bus can be keyed to appear over the
existing video on the program bus, using an RGB key, a luminosity level key, or a
transparency effect. To configure, see
3. Press and release the TAKE button to execute the selected effect.

Recalling a Layout Preset

Layout presets are used to preconfigure a presentation prior to going live (see the
ISS 608 PCS Help File to configure a layout preset). This minimizes missed cues or incorrect
video layout. A layout preset captures transition effect settings, a logo preset, the input
channel, and any picture control adjustments made to the preview output (for a list of all the
layout preset options, see the Layout Presets table below). When recalled, layout presets
apply the settings to the preview output to review the configuration before TAKE is pressed
to make it live on the program output.
Selected effect
Effect duration
Wipe effect type
Video Key effect type
Video Key effect levels
Dissolve on page 20.
PIP on page 21.
Video Key
Layout Presets
Logo preset
Window size
Window position
Image position
Image size
