User-selectable HDCP authorization — Allows each HDMI input to appear HDCP
•
compliant or non-HDCP compliant to the connected source, which is beneficial if the
source automatically encrypts all content when connected to an HDCP-compliant
device. Protected material is not passed in non-HDCP mode.
• HDCP Visual Confirmation provides a green signal when encrypted content
is sent to a non-compliant display — A green window with an alert message is
displayed when HDCP-encrypted content is transmitted to a non-HDCP compliant
display, providing immediate visual confirmation that protected content cannot be
viewed on the display.
• Key Minder continuously verifies HDCP compliance for quick, reliable
switching — Key Minder authenticates and maintains continuous HDCP encryption
between input and output devices to ensure quick and reliable switching in professional
AV environments, while enabling simultaneous distribution of a single source signal to
one or more displays.
• SpeedSwitch Technology delivers virtually instantaneous switching speeds for
HDCP-encrypted content.
EDID Minder automatically manages EDID communication between connected
•
devices — EDID Minder ensures that all sources power up properly and reliably output
content for display.
• EDID capture mode — EDID information can be captured and stored from connected
program and preview display devices.
Comprehensive picture controls for Preview and Program output buses — Fine
•
tune displayed content with picture controls for brightness, contrast, sizing, positioning,
and zoom.
Internal video test patterns and pink noise generator for calibration and setup
•
— The ISS offers several video test patterns and audio pink noise to facilitate proper
system setup and calibration of display devices.
• Audio management — Embedded two-channel digital audio can be extracted from
any input and sent to the Preview and Program analog audio outputs. Multi-channel
audio formats can be passed to the Preview and Program HDMI outputs.
• Easy setup and commissioning with Extron PCS - Product Configuration
Software — Convenient configuration and preset design from a single easy-to-use
software application.
• Front panel controls with LCD display — Back-lit front panel buttons and an LCD
menu system with navigation controls ensure simplified operation in live presentation
environments and provide quick access to configuration settings.
• Ethernet monitoring and control — Enables control and proactive monitoring over a
LAN or WAN.
• Built-in web pages — Enables the use of a standard browser for device monitoring
and simple troubleshooting over an intuitive web interface.
• RS-232 control port — Supports the use of serial commands for integration into
a control system. Extron products use the SIS - Simple Instruction Set command
protocol, a set of basic ASCII commands that allow for quick and easy programming.
• Front panel USB configuration port — Enables easy configuration without having to
access the rear panel.
Executive Mode lockout — Provides restriction to access of controls.
•
• Includes LockIt HDMI cable lacing brackets.
Rack-mountable 2U, full rack width metal enclosure.
•
