Auto Memory
Auto Memory is enabled on all inputs by default (see
only be disabled if the user desires to have a source applied to the input treated as a new
source, regardless of whether the source was detected previously.
Auto Memory saves the main window size, main image size , PIP image size and position,
brightness, contrast, and detail settings. Digital inputs are automatically set up using
information regarding image size and refresh provided by the digital input. This allows for
non-standard rates (not found in the input lookup table) to display correctly. Digital inputs
that do not match an existing lookup table are saved to Auto Memory as unique entries
based on the total line count, H/V active, and vertical refresh rate.
1. Rotate the horizontal ( [ ) ADJUST knob to select the input.
2. Rotate the vertical ( { ) ADJUST knob to select On (default) or Off.
Screen Saver
Select a screen saver to display when an input with no detected source is routed to an
output (see figure 19).
1. Rotate the horizontal ( [ ) ADJUST knob to select Color or IMG.
2. Rotate the vertical ( { ) ADJUST knob:
If Color was previously selected, select Black (default) or Blue.
•
• If IMG was previously selected, select a preconfigured image.
Screen Saver Timeout
Select whether the screen saver should timeout or remain until a new input is routed to the
output. Screen saver mode is activated when an input with no detected signal is routed to
an output (see figure 19).
NOTE: If PIP or VIDEO KEY is enabled, the screen saver should not be enabled,
regardless of signal presence. If PIP or VIDEO KEY is enabled while in screen saver
mode, the ISS exits screen saver mode.
• Rotate either ADJUST knob to select a timeout setting. Options are: Never or a duration
from Instant (0) to 500 seconds in
Preview Switch Mode
Set the channel the preview output displays after a switch has occurred (see figure 19).
Rotate either ADJUST knob to select the preview switch mode. Options are: Swap
•
(default) or Stay.
• Swap mode — The preview and program outputs are swapped. The video and
audio signals on the preview output are applied to the program output. The video
and audio signals that had been applied to the program output are applied to the
preview output.
• Stay mode — The video and audio signals on the preview output are applied to
the program output and also continue on the preview output until another input is
selected.
Temperature
View the internal temperature of the unit. The temperature displays in both Celsius (°C) and
Fahrenheit (°F) (see figure 19).
figure 19 on page 25). It should
second intervals.
1
ISS 608 Seamless Switcher • Operation 26
