Reference
Information
Topics covered in this section are:
•
•

Mounting the Switcher

Four uninstalled rubber feet are included with the seamless switcher. If you are going to
rack mount the switcher, mount it before you cable it (see Rack Mounting), and do not
install the rubber feet. If you are not rack mounting the seamless switcher, see Tabletop
Placement.

Tabletop Placement

For tabletop placement, install the self-adhesive rubber feet/pads (provided) onto the four
corners of the bottom of the seamless switcher.

Rack Mounting

UL guidelines
The following Underwriters Laboratories (UL) guidelines pertain to the installation of the
ISS 608 into a rack.
1.
2.
3.
4.
5.
Mounting the Switcher
Front Panel Menu Diagrams
Elevated operating ambient temperature — If the equipment installed in a closed
or multi-unit rack assembly, the operating ambient temperature of the rack environment
may be greater than room ambient temperature. Therefore, install the ISS in an
environment compatible with the maximum ambient temperature (Tma = +122 °F,
+50 °C) specified by Extron.
Reduced air flow — Install the equipment in a rack so that the amount of air flow
required for safe operation of the equipment is not compromised.
Mechanical loading — Mount the equipment in the rack so that a hazardous
condition is not achieved due to uneven mechanical loading.
Circuit overloading — Connect the equipment to the supply circuit and consider the
effect that circuit overloading might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be used when
addressing this concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to supply connections other than direct connections
to the branch circuit (that is, use of power strips).
ISS 608 Seamless Switcher • Reference Information 74
