SP 1
Setpoint action
Act
rEL.1
To select a setpoint:
Scroll to the desired setpoint using the up/down arrow keys.
To view the setup options for the setpoint:
SELECT
Press
Use the up/down arrow keys to scroll to the desired setup option. The value
associated with this option is displayed in the lower window.
To change the selected setup option:
Press
SELECT
Use the up/down arrow keys to scroll to the desired value.
ENTER
Press
Press to leave the value unchanged.
ESC
To store your new setup for the setpoint:
From the middle window, press
To quit the setpoint setup without changes:
From the middle window, press
To quit the setpoints setup menu:
From the upper window, press
NOTES
1. If your instrument is not equipped with the optional relay, then these setup
parameters will not appear on the display.
2. When you enter the setpoints setup menu at the protected level, monitoring setpoints
is temporarily suspended until you return to the main setup menu.
3. Each time you select a new trigger parameter, the operate and release limits are set
by default to zero.
4. You will not be able to store your setpoint setup to the instrument if a setpoint action
is directed to a relay allocated for pulsing.
5. The setpoint action directed to a relay output can be overridden using commands
sent via communications. A relay can be manually operated or released. When the
relay reverts to normal operation, it is automatically returned under setpoint control.
28
The action to be triggered is operation of relay #1.
to activate the middle window.
to activate the lower window.
to store the new value.
ENTER
.
ESC
or
ESC
.
.
ENTER
