Satec C191HM Installation And Operation Manual page 50

common measurements parameters.
Selecting Min/Max Measurements
MAX/MIN
Press the
Min/Max measurements.
Selecting Total Harmonic Measurements
Press the
H/ESC
up/down arrow keys to scroll through the different harmonic parameters.
Selecting Individual Voltage Harmonics Measurements
Press the
H/ESC
LEDs at the right are lit. Use the up/down arrow keys to scroll through the
different harmonics readings.
Selecting Individual Current Harmonics Measurements
Press the
H/ESC
LEDs at the right are lit. Use the up/down arrow keys to scroll through the
different harmonics readings.
Selecting Energy Measurements
Press the
ENERGY
different energy readings.
Fast Reset of Accumulated Data
Select a display page where the data you want to reset is displayed. To reset:
• Min/Max log registers: select a Min/Max page from the Min/Max
measurements display (where a MAX or MIN round LED is illuminated).
• Ampere and volt maximum demands: select the ampere or volt maximum
demand page from the Min/Max measurements display (where a MAX
DMD LED is illuminated, and volts or amps LEDs at the right are lit).
• Power maximum demands: select the power maximum demand page from
the Min/Max measurements display (where a MAX DMD LED is illuminated,
and kVA/MVA and kW/MW LEDs at the right are lit).
• Total and phase energies: select the energy measurements display.
While holding the
The displayed data is reset to zero.
Chapter 5 Data Display
key. Use the up/down arrow keys to scroll through
key until the THD/TDD LED is illuminated. Use the
key until the HARMONICS LED is illuminated and volts
key until the HARMONICS LED is illuminated and amps
key. Use the up/down arrow keys to scroll through the
key, press and hold
SELECT
for about 5 seconds.
ENTER
41
