NOTE: Pmax is rounded to nearest whole kW units.
If Pmax is more than 9999.000 kW, it is truncated to 9999.000 kW
Wiring via PTs (PT Ratio > 1):
Vmax (690 V input option) = 144 × PT Ratio [V]
Vmax (120 V input option) = 144 × PT Ratio [V]
Pmax = (Imax × Vmax × 3)/1000 [MW x 0.001] @ wiring modes 4Ln3, 3Ln3
Pmax = (Imax × Vmax × 2)/1000 [MW x 0.001] @ wiring modes 4LL3, 3OP2, 3dir2, 3OP3, 3LL3
NOTE: Pmax is rounded to nearest whole kW units.
The actual frequency range is 45.00 - 65.00 Hz

4.5 Pulsing Output Setup Menu

SELECT CHG
This menu allows you to program any of the eight relays provided by your
C191HM instrument to output energy pulses. Relays #7 and #8 are especially
recommended for use as pulsing relays because of their high endurance.
Available pulsing parameters are listed in Table 4-5.
To select a pulse relay:
rEL.1
Ac.Ei
1
To change the pulse relay setup:
To quit the pulsing setup menu:
Table 4-5 Pulsing Output Parameters
Code Parameter
nonE Output disabled
Ac.Ei Active energy import
Ac.EE Active energy export
Reactive energy import
rE.Ei
rE.EE Reactive energy export
rE.Et Reactive energy total
AP.Et Apparent energy total
26
ENTER
Use the up/down arrow keys to scroll to the desired relay. The
pulsing parameter assigned to the relay is displayed in the
middle window, and the amount of unit-hours per pulse is
displayed in the lower window.
SELECT
Press to activate the middle window.
Use the up/down arrow keys to scroll to the desired output
parameter. Selecting nonE disables pulsing through this relay.
SELECT
Press to activate the lower window.
Use the up/down arrow keys to set the amount of unit-hours
per pulse. The available range is 1-9999.
ENTER
Press to store the new setup, or press
setup without changes.
From the upper window, press
Units
kWh import (positive)
kWh export (negative)
kvarh import (inductive)
kvarh export (capacitive)
kvarh total (absolute)
kVAh total
PulS
ENTER
ESC to quit the
ESC
ENTER
or .
Chapter 4 Setup Menus
