Chapter 2 Installation
2.
2.1 Mechanical Installation
Prepare the panel cut-out, 136 x 136 mm, prior to mounting.
STEP 1: Place the instrument through the cut-out.
STEP 2: Assemble the latches onto the outer wall of the enclosure.
STEP 3: Tighten the screws.
C 1
9 1
H M
Chapter 2 Installation
S T
E P
S T
3
E P
2
S T
Figure 2-1 Mounting the C191HM
1 3
6 . 0
+ 1
. 0
E P
1
c99-09046/2
7
