Table 4-6 Setpoint Setup Options (middle window)
Code Option
triG Trigger parameter
On Operate limit
OFF Release limit
On d Operate delay
OFF d Release delay
Act Setpoint action
Table 4-7 Setpoint Triggers (lower window, when middle window is triG)
Code
nonE Setpoint disabled
Status Input
St.On Status input ON
St.OFF Status input OFF
Phase Reversal
POS.ro. Positive phase rotation reversal
NEG.ro. Negative phase rotation reversal
Real-time Values on any Phase
High voltage
r. Hi. U
Low voltage
r. Lo. U
r. Hi. C High current
Low current
r. Lo. C
High voltage THD
r. thd.U
High current THD
r. thd.C
High K-factor
r. HFc.C
High current TDD
r. tdd.C
Real-time Auxiliary Measurements
High frequency
r. Hi.Fr
r. Lo.Fr Low frequency
Average Values per Phase
A. Hi.C1 High current L1
A. Hi.C2 High current L2
A. Hi.C3 High current L3
A. Lo.C1 Low current L1
A. Lo.C2 Low current L2
A. Lo.C3 Low current L3
Average Values on any Phase
A. Hi. U High voltage
A. Lo. U Low voltage
A. Hi. C High current
A. Lo. C Low current
Average Total Values
A. Hi.P.i High total kW import (positive)
A. Hi.P.E High total kW export (negative)
A. Hi.q.i High total kvar import (positive)
A. Hi.q.E High total kvar export (negative)
A. Hi. S High total kVA
A. PF.LG Low total PF Lag
Chapter 4 Setup Menus
Description
The measurement parameter or signal to be monitored
by the setpoint.
The threshold at which the setpoint becomes operative.
The threshold at which the setpoint is released (becomes
inoperative).
The time delay (0.1 second resolution) before operation
when the operate condition is fulfilled.
The time delay (0.1 second resolution) before release
when the release condition is fulfilled.
The action performed when the setpoint is operative.
Parameter Unit Range
V 0 to Vmax
V 0 to Vmax
A 0 to Imax
A 0 to Imax
% 0 to 999.9
% 0 to 999.9
% 1.0 to 999.9
% 0 to 100.0
Hz 0 to 100.00
Hz 0 to 100.00
A 0 to Imax
A 0 to Imax
A 0 to Imax
A 0 to Imax
A 0 to Imax
A 0 to Imax
V 0 to Vmax
V 0 to Vmax
A 0 to Imax
A 0 to Imax
kW 0 to Pmax
kW 0 to Pmax
kvar 0 to Pmax
kvar 0 to Pmax
kVA 0 to Pmax
0 to 1.000
