Satec C191HM Installation And Operation Manual page 39

Code
A. PF.Ld Low total PF Lead
Average Auxiliary Measurements
Ar neU.C High neutral current
Ar Hi.Fr High frequency
Ar Lo.Fr Low frequency
Present Demands
Hi d.U1 High volt demand L1
Hi d.U2 High volt demand L2
Hi d.U3 High volt demand L3
Hi d.C1 High ampere demand L1
Hi d.C2 High ampere demand L2
Hi d.C3 High ampere demand L3
Hi d.P High block interval kW demand
Hi d.S High block interval kVA demand
Hi Sd.P High sliding window kW demand
Hi Sd.S High sliding window kVA demand
Hi Ad.P High accumulated kW demand
Hi Ad.S High accumulated kVA demand
Hi Pd.P High predicted sliding window kW demand
Hi Pd.S High predicted sliding window kVA demand
High Voltage Harmonic Distortions on any Phase
Hd03.U High voltage harmonic H03
Hd05.U High voltage harmonic H05
... ...
Hd39.U High voltage harmonic H39
High Current Harmonic Distortions on any Phase
Hd03.C High current harmonic H03
Hd05.C High current harmonic H05
... ...
Hd39.C High current harmonic H39
For parameter limits, see notes to Table 4-4.
The setpoint is operated when the actual phase sequence does not match the indicated
normal phase rotation.
The actual frequency range is 45.00 - 65.00 Hz.
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for
any other wiring mode, they will be line-to-line voltages.
30
Parameter Unit Range
0 to 1.000
A 0 to Imax
Hz 0 to 100.00
Hz 0 to 100.00
V 0 to Vmax
V 0 to Vmax
V 0 to Vmax
A 0 to Imax
A 0 to Imax
A 0 to Imax
kW 0 to Pmax
kVA 0 to Pmax
kW 0 to Pmax
kVA 0 to Pmax
kW 0 to Pmax
kVA 0 to Pmax
kW 0 to Pmax
kVA 0 to Pmax
% 0 to 100.00
% 0 to 100.00
% 0 to 100.00
% 0 to 100.00
% 0 to 100.00
% 0 to 100.00
Chapter 4 Setup Menus
