Summary of Contents for Otto Bock Skippi Plus

  • Page 1 Skippi Plus Instructions for use...
  • Page 2 Additional options for the Skippi Plus INFORMATION Before the power wheelchair is handed over, the qualified personnel must check off the additional options listed below if they are present on the power wheelchair. The power wheelchair can be equipped with the following additional options:...
  • Page 3: Table Of Contents

    Adjustment options ..........41 2.7.1 General information on electromagnetic interference 20 6.1.1 Backrest .............. 41 2.7.2 Warnings regarding effects of electromagnetic 6.1.2 Seat angle ............42 interference ............21 2.7.3 Interference immunity of this power wheelchair ..22 Ottobock | 3 Skippi Plus...
  • Page 4 Releasing and engaging the brake ....... 61 7.3.5 Special controls ........... 81 Batteries .............. 62 Control panel holder ..........81 6.5.1 Charging .............. 64 7.4.1 Swing-away control panel holder with removable control panel ............81 6.5.2 Charger ............... 65 Ottobock Skippi Plus |...
  • Page 5 Safety instructions ..........94 Maintenance intervals ........... 95 Replace the fuses ..........98 Replacing the tyres/inner tubes ......98 Replacing a defective bulb ......... 100 Cleaning and care ..........101 9.6.1 Disinfection ............102 Disposal ............102 Ottobock | 5 Skippi Plus...
  • Page 6: General Information

    „ It is possible to increase the display size of the PDF Intended use document. The Skippi Plus power wheelchair for children is designed „ For further questions about the instructions for use, solely for use by children and small persons who are unable...
  • Page 7: Area Of Application

    General information The Skippi Plus is a power wheelchair for children for indoor Area of application and outdoor use according to category B of EN 12184. The Skippi Plus power wheelchair for children is suitable for persons having the inability to walk or walking impediments...
  • Page 8: Service

    Standards and directives All safety information contained in these instructions for use refers to the currently valid national laws and regulations of the European Union. In other countries, compliance with the applicable laws and national regulations is required. Ottobock Skippi Plus |...
  • Page 9: General Safety Instructions

    „ Children may not use the power wheelchair without su- pervision. WARNING „ Only one person may be transported in the power Risk of suffocation. Packaging materials must be kept out wheelchair at any one time. of reach of children. Ottobock | 9 Skippi Plus...
  • Page 10: Safety Requirements For Transportation, Storage And Assembly

    (such as lap vent injuries by coming into contact with the parts. belt) which are offered by Ottobock and suitable restraint systems are used. Observe the limitations regarding installed options (see section 5.1.3). Ottobock Skippi Plus |...
  • Page 11 Battery damage due to deep discharge. Remove the circuit. For more information please visit the www.iata.org fuse for shipping or when the power wheelchair is not be- website. ing used for an extended period of time. Ottobock | 11 Skippi Plus...
  • Page 12: Safety Requirements For Operation

    Risk of accidents and injury due to incorrect configura- per. To ensure safe driving operation, the anti-tipper must tion settings. Modified parameter settings in the configu- be mounted correctly and must be in good condition. ration can lead to changes in driving characteristics. In Ottobock Skippi Plus |...
  • Page 13 7° (12 %). Navigating inclines above ing on very smooth areas (e. g. icy surfaces) or extremely this value is not permitted. rough terrain (e. g. gravel or rubble) is not permitted. Ottobock | 13 Skippi Plus...
  • Page 14 Due to the design, areas which „ User and attendants must not reach into the danger can cause pinching or crushing injuries when the seat zone. height, back angle, and seat tilt adjustments are activated Ottobock Skippi Plus |...
  • Page 15 CAUTION Risk of accidents due to bad tyres. Visually inspect the tyres for sufficient tread depth and correct pressure before each use. Ottobock | 15 Skippi Plus...
  • Page 16 „ The electric seat function may not be activated in case wheelchair is equipped with a seat height adjustment unit, of faults or malfunction. then the maximum load capacity is 50 kg / 110 lbs. This load capacity must not be exceeded. Ottobock Skippi Plus |...
  • Page 17 INFORMATION If the control unit does not emit an error signal when the brake lever is activated, this indicates a malfunction. The setting must be checked by a specialist dealer. Ottobock | 17 Skippi Plus...
  • Page 18: Safety Requirements For Care, Maintenance And Disposal

    Maintenance work on the power wheelchair may only be completed by personnel au- thorised and trained by Ottobock. This also applies to all repairs and settings on the brake. Incorrect settings can lead to brake failure. Ottobock Skippi Plus |...
  • Page 19: Effects Of Electromagnetic Interference On The Product And On The User

    Never use a water jet or high-pressure cleaning apparatus the possible effects of electromagnetic interference on to clean the power wheelchair. Water must not come into your power wheelchair. direct contact with the electronics, motor or batteries un- der any circumstances. Ottobock | 19 Skippi Plus...
  • Page 20: General Information On Electromagnetic Interference

    „ Because EM energy rapidly becomes more intense as these sources are obvious and easy to avoid. Others are one move closer to the transmitting antenna (source), the not apparent and exposure is unavoidable. However, we EM fields from hand-held radio wave sources (transceiv- Ottobock Skippi Plus |...
  • Page 21: Warnings Regarding Effects Of Electromagnetic Interference

    WARNING Risk of accidents due to uncontrolled driving behaviour. Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios, and mobile phones can affect power Ottobock | 21 Skippi Plus...
  • Page 22: Interference Immunity Of This Power Wheelchair

    Malfunctions such as an insufficient supply of power to the brake are recognised by the software, triggering an emer- gency stop or reducing the speed of the power wheelchair. A warning signal will also sound. Ottobock Skippi Plus |...
  • Page 23 The power wheelchair is fully functional again once the unit has cooled down sufficiently (this may take several minutes depending on the ambient temperature). Ottobock | 23 Skippi Plus...
  • Page 24: Signage On The Product

    Safety Signage on the product CLOSE CLOSE Ottobock Skippi Plus |...
  • Page 25: Warning Symbols And Type Plates

    J Manufacturer / address The rating plate is located on the side of the K Product reference number frame below the seat. Engage the locking bar before use. Observe the information in the in- structions for use. CLOSE Ottobock | 25 Skippi Plus...
  • Page 26 Safety Label Meaning A Electric driving mode: lock motor brake B Manual pushing mode: unlock motor brake
 Pinch points on account of the construction. Users and attendants must not reach into the danger area. Ottobock Skippi Plus |...
  • Page 27: Product Description

    Product description Special features of the Skippi Plus power wheelchair in- Product description clude: The Skippi Plus is a power wheelchair for children for indoor „ Compact design. and outdoor use according to category B of EN 12184. „ Easy operation.
  • Page 28: Delivery And Preparation For Use

    Seat cushion Locking lever Footrest Detachable push handle The optional toolkit contains a set of Allen wrenches (3, 4, 5, 10 Plug with battery cable and 6 mm) and a 13 mm open-end wrench. Ottobock Skippi Plus |...
  • Page 29: Initial Operation

    (see section 6.5 / 6.5.1). Ensure that the battery cable is seated securely in the plug (fig. 2, item 10) or push the cable into the plug if necessary. Ottobock | 29 Skippi Plus...
  • Page 30: Transportation And Storage

    Transportation and storage Transportation and storage Once the battery packs are removed, the Skippi Plus can be transported as a ready-to-operate power wheelchair for children. Fig. 4 Removed battery packs Transportation in a vehicles for transporting persons with reduced mobility Fig. 3...
  • Page 31 Four eyelets are provided on the For more information, please refer to our brochure on us- frame of the Skippi Plus in order to attach straps (fig. 5 a, ing Ottobock products in vehicle for transporting persons 5 b).
  • Page 32: Required Accessories

    The qualified personnel which fit the wheelchair can provide more information. 5.1.2 Using the product in the vehicle Fig. 5 c Engaged attachment straps at the front and rear The power wheelchair has been tested according to ANSI/ RESNA and ISO 7176-19. Ottobock Skippi Plus |...
  • Page 33: Restrictions For Use

    „ Please note that certain settings on the product exclude the use of the product in a vehicle for transporting per- sons with reduced mobility. Fig. 5 d Restraint lap belt hooked onto pin Ottobock | 33 Skippi Plus...
  • Page 34 * The seat belt can be used to position the passenger during transportation. Using the personal restraint system is never- theless required. For more information please refer to section 5 of the brochure on using Ottobock products in vehicle for transporting persons with reduced mobility, order number 646D158. Ottobock Skippi Plus |...
  • Page 35: Disassembling The Power Wheelchair

    Please observe the following order for disassembly: 1. Remove the footrests (fig. 6). 2. Remove the control panel from the armrest and carefully Fig. 7 Removing the control panel lay it down on the ground (fig. 7). Ottobock | 35 Skippi Plus...
  • Page 36 5. Release the seat lock by pulling on the release strap and folding the locking bar back at the same time (fig. 10). Now the battery packs are accessible. 6. Remove the battery packs (fig. 11). Fig. 8 Removing the side panels Ottobock Skippi Plus |...
  • Page 37 8. Now the frame can be separated from the drive unit by lifting it slightly and pulling it back (fig. 13). Fig. 10 Releasing the seat lock Fig. 12 Push the step points (frame protection rollers) down Fig. 11 Removing the battery packs Ottobock | 37 Skippi Plus...
  • Page 38 (fig. 12) or placed into the corresponding holder. Ensure that the control panel is not switched on and that cables are not pinched. Now the power wheelchair is ready to transport and can be stowed in a vehicle. Ottobock Skippi Plus |...
  • Page 39 Perform the steps listed above in reverse order to reassem- ble the Skippi Plus power wheelchair. Ensure that the locking bar is pushed back into its proper position (see fig. 14 a, item 1) and both locking pins engage correctly (see fig.
  • Page 40: Storage

    INFORMATION Direct exposure to sunlight/UV radiation causes the tyres to age more quickly. As a result, the tread surface hardens and corner pieces break out of the tread. Ottobock Skippi Plus |...
  • Page 41: Operation

    The user can make all adjustment options using the optional Adjustment options available toolkit or by hand. CAUTION The Skippi Plus power wheelchair for children can be disas- sembled easily by an attendant (see section 5.2 Disassem- Risk of accidents due to unsecured screw connections. bling the power wheelchair).
  • Page 42: Seat Angle

    2. Pull the side panel with armrest up and out. 4. Check that the retaining clip on the pin is closed every 3. Retighten the thumb screw properly after reinstalling the time after the seat angle is adjusted. side panel. Ottobock Skippi Plus |...
  • Page 43 2. Move the side panel with armrest up or down the rail to placement tube forward or backwards along the attach- the desired position. ment rail to the desired position. 3. Retighten the Allen head screw properly. 3. Retighten all set screws. Ottobock | 43 Skippi Plus...
  • Page 44: Control Panel

    NOTICE Cable damage. Positioning the cable incorrectly can lead to pinching and thus damage to the cable. The cable must not be too tight or too loose. Avoid bending or crushing the cable. Ottobock Skippi Plus |...
  • Page 45 2. Move the control panel with the control panel holder or replacement tube forward or backwards along the at- tachment rail to the desired position. 3. Retighten all set screws. Ottobock | 45 Skippi Plus...
  • Page 46: Footrest

    (fig. 24, right). 2. Pull the footrest up and remove it. 4. Re-tighten the screws properly. Installing the footrests 1. Slide the footrest into the holder from above until the latch clicks in place. Ottobock Skippi Plus |...
  • Page 47 (fig. 26). 1. Loosen the corresponding two screws on the seat frame. 2. Move the footrest holder to the desired position. 3. Re-tighten the screws properly. Fig. 26 Footrest holder: Adjusting the lateral position Ottobock | 47 Skippi Plus...
  • Page 48: Getting In And Out

    To get in from the side, the right or left side panel corre- Fig. 27 Preparing to get into the chair from the side sponding to the entry side must be removed. If possible, al- ways get in on the side opposite the control panel. Ottobock Skippi Plus |...
  • Page 49: From The Front

    Risk of impairing the driving performance of the power wheelchair. The driving characteristics of the power wheelchair can be affected by electromagnetic fields (mo- bile phones or other radiating devices). Therefore all mo- Fig. 28  Footrests flipped up bile devices must be turned off while driving. Ottobock | 49 Skippi Plus...
  • Page 50: Control Panel

    1 by pressing the button again (1-2-3-4- 5-1-…). Pushing and holding the button for at least 2 sec- onds switches the control unit to the “Electric seat function” menu. Ottobock Skippi Plus |...
  • Page 51 It indicates the selected speed Open-end wrench 16 Light level, the remaining battery capacity and the status of elec- tric options and special functions as well as warnings and errors. All display symbols are visible during the initialisation phase. Ottobock | 51 Skippi Plus...
  • Page 52: Separate Lcd Monitor

    The power wheelchair controls are turned on or off by press- „ Please contact your authorised dealer. ing the on/off button (see fig. 30, item 6). The wheelchair turns off automatically if the control panel is not used for an Ottobock Skippi Plus |...
  • Page 53 Obstacles such as steps or curbs „ Do not cross obstacles with a difference in height must be crossed at reduced speeds. > 60 mm / 2,4". „ Do not cross steps or curbs without reducing speed. Ottobock | 53 Skippi Plus...
  • Page 54 “M” button to increase the speed level. After reaching the all minimum requirements (for more information see the maximum speed level, the control unit switches back to section “Appendix” > “Threshold values for wheelchairs speed level 1. transportable by train”. Ottobock Skippi Plus |...
  • Page 55: Battery Charge Level" Display

    As the remaining battery charge decreases, the eration values to the individual wishes of the user. LCD segments turn off one by one (see table 1). When the last segment flashes, the battery must be charged immediately. Ottobock | 55 Skippi Plus...
  • Page 56: Range

    Please note that the specified range was determined un- der defined conditions in accordance with ISO 7176-4. In Charging process with practice the range can be reduced by up to 50 %. drive-away lock Ottobock Skippi Plus |...
  • Page 57: Controlling Additional Electrical Functions

    The currently se- cally at the same time, forward and down or back and up. lected function is shown on the LCD monitor. The respective function can be extended or retracted by moving the joystick Ottobock | 57 Skippi Plus...
  • Page 58: Drive-Away Lock

    3. The control unit is turned off automatically. Tab. 2 Display of electric seat functions on the control panel 4. Activation of the drive-away lock is indicated by the key symbol on the display. Ottobock Skippi Plus |...
  • Page 59 Deactivation via separate LCD monitor An information screen is shown on the LCD monitor after the power wheelchair is switched on. The deactivation process is the same as described under “Deactivation via control panel”. Ottobock | 59 Skippi Plus...
  • Page 60: Steering Lock

    „ When the joystick is deflected forward, the power wheel- chair drives straight ahead. „ When the joystick is deflected backward, the power wheelchair drives straight back. „ Turning is not possible when the steering lock is activat- Ottobock Skippi Plus |...
  • Page 61: Releasing And Engaging The Brake

    „ The brake function may only be released in the pres- ence of an attendant. „ Should the user be unable to release the brake himself, the brake can be released by the attendant. Fig. 33 Engaging/disengaging the brake Ottobock | 61 Skippi Plus...
  • Page 62: Batteries

    INFORMATION Before doing any maintenance work on the batteries, INFORMATION please read the warnings thoroughly. Observe the dispos- The control unit may be switched off in push mode. al information (see section 10). Ottobock Skippi Plus |...
  • Page 63 Due to the sealed design, the AGM technology used fulfills 4. The locking lever should be engaged again to prevent the latest safety and environmental compatibility provisions. the battery packs from falling out (fig. 10). Ottobock | 63 Skippi Plus...
  • Page 64: Charging

    „ Ensure that no sparks are generated. power wheelchair accordingly. Moreover the charge level displayed on the control panel can differ more significantly from the actual battery capacity. The following applies for an optimal charging frequency: Ottobock Skippi Plus |...
  • Page 65: Charger

    The battery charger is designed for AGM batteries (mainte- ing current to be fed into the battery. nance-free batteries). The charger is programmed with the Ottobock | 65 Skippi Plus...
  • Page 66: Charging Process

    LED indi- location. Avoid letting dust and dirt enter the battery cators. charger. This can impair the battery charger functionali- „ Use a dry cloth to clean the battery charger. Ottobock Skippi Plus |...
  • Page 67: Accessories

    „ Slightly tilt the seat to the rear when driving forwards down inclines or over obstacles (e.g. curbs) and reduce The Skippi Plus power wheelchair has been designed as a the speed. modular system. Certain modules can be exchanged and other accessories can be added.
  • Page 68 „ Ensure that no body parts, such as hands or feet, are in function for this purpose. the danger area while electric seat options are used. „ Only activate the electric seat functions if no fault or er- ror is present. Ottobock Skippi Plus |...
  • Page 69: Seat Height Adjustment

    Ensure that guarantee proper operation of the seat height adjustment creep speed is activated when the seat height adjust- function. ment function is used. If this is not the case, contact a Ottobock | 69 Skippi Plus...
  • Page 70 The function is activated with the joystick in Additional func- tions / Seat functions mode (see section 6.3.7 and 7.3.1). Fig. 37 Creep speed – Control panel display / LCD display Fig. 36 Seat with activated seat height adjustment function Ottobock Skippi Plus |...
  • Page 71: Electric Seat Tilt

    (lap belt, four-point belt) and do not The function is activated with the joystick in Additional func- lean out beyond the seat surface with the seat raised. tions / Seat functions mode (see section 6.3.7 and 7.3.1). Ottobock | 71 Skippi Plus...
  • Page 72 „ Remove the side panels and fold down the seat back tions / Seat functions mode (see section 6.3.6 and 7.1.1). onto the seat bottom. Fig. 40 Locking the cross bolt in the holder Fig. 39 Electric back angle adjustment Cross bolt Lock with lever Ottobock Skippi Plus |...
  • Page 73: Manual Seat Functions

    „ Ensure that no body parts, such as hands or feet, are in the danger area while manual seat options are used. Ottobock | 73 Skippi Plus...
  • Page 74: Mechanically Elevating Footrests

    7.3.1.1 Functional overview The attendant control can be used to operate the driving function and the electric seat functions. The module can be connected to the control unit in combi- nation with the hand control device or separately. Ottobock Skippi Plus |...
  • Page 75 Continue driving slowly Red/Orange/Green flash- Charging process / The control panel displays the following after the attendant ing alternately drive away lock control is turned on: Tab. 6 Display of battery charge level Ottobock | 75 Skippi Plus...
  • Page 76 The electric seat functions are accessed by pressing and functions. The selected function can be extended or retract- holding the "M" button (approx. 2 seconds). ed by moving the joystick forward or backward (also see section 6.3.7). Ottobock Skippi Plus |...
  • Page 77: Push-Button Module

    Ottobock modular system or modifications item 4) (function up / down). made later on by the user are not permissible. The push button module lets the user select additional elec- trical functions directly during normal driving operation. Ottobock | 77 Skippi Plus...
  • Page 78 Fig. 44 Push button module Available electrical functions Up/down arrow buttons (see information box) Function select” mode button Selected function” Stereo plug to connect LED indicator Buddy buttons Mode LED Ottobock Skippi Plus |...
  • Page 79: 2X Adapter Cable For Piko Button

    Ottobock includes an interface for alternate input devices (environment and special controls) with the LCD monitor. Ottobock does not assume any liability for combi- nations involving third-party special controls. Fig. 45 LCD module with infrared Ottobock | 79 Skippi Plus...
  • Page 80 Special functions, e.g. coupled electric Charging process with drive-away lock seat adjustment (back adjustment and seat tilt) Creep speed Drive-away lock Tab. 9 Information displayed on the LCD monitor Electric seat height adjustment (optional) Ottobock Skippi Plus |...
  • Page 81: Special Controls

    INFORMATION Detailed information on the respective controls can be found in the respective included instructions for use "Spe- cial controls" (serial number: 647G636). Note that the Skippi Plus cannot be equipped with a foot control. Control panel holder Fig. 46 Control panel holder, swing-away 7.4.1 Swing-away control panel holder with removable...
  • Page 82: Lap Belt

    Do not modify the instal- the area of the soft part of the stomach. lation position and basic settings established by the  The user is not sitting upright in the seat. qualified personnel. Ottobock Skippi Plus |...
  • Page 83 Positioning the lap belt Adjusting the belt length The belt length can be adjusted on both sides. Excess belt length is taken up by the plastic slider. Fig. 48 Adjusting the lap belt Belt buckle Ottobock | 83 Skippi Plus...
  • Page 84: Use

    2. Pull to check that it is secure.  Information about subsequent acquisition and moun- ting is provided by the qualified personnel that handed the product over to you. Ottobock Skippi Plus |...
  • Page 85: Lights

     Belts with metal snaps may not be washed in washing machines as the penetration of water could cause cor- To replace broken lamps, see the section “Replacing a de- rosion and subsequent malfunctions. fective bulb”. Ottobock | 85 Skippi Plus...
  • Page 86: Additional Options

    „ Tray centre control unit (only as custom fabrication) „ Puncture-proof tyres: Solid rubber tyres These and other optional add-on components are included on the order form and in the wheelchair accessories catalogue. Fig. 51 Front lights Ottobock Skippi Plus |...
  • Page 87: Malfunctions/Troubleshooting

    Electrostatic discharge may also occur if the power wheel- chair is equipped with puncture-proof tyres. Retrofitting the wheelchair with pneumatic tyres can correct this problem. Ottobock | 87 Skippi Plus...
  • Page 88: Warning

    If the driving function is still not available after switching the control unit on again, the brake can be deactivated (see section 6.4) to switch over to pushing mode. Contact a specialist dealer immediately after an emergency stop! Ottobock Skippi Plus |...
  • Page 89: Fault Indication: Control Panel / Lcd Display

    Move the joystick to the Joystick warning home position when the home position before unit is turned on turning the unit on Hand control device Defective joystick Contact specialist dealer fault Controller fault Defective controller Contact specialist dealer Ottobock | 89 Skippi Plus...
  • Page 90 Battery over voltage full charge and driving Continue driving slowly downhill) Back angle adjust- ment motor fault Faulty cabling or plug Check cabling / plug contacts; connections; Defective actuator Contact specialist dealer Seat tilt motor fault Ottobock Skippi Plus |...
  • Page 91 Drive motor fault Brake disengaged Engage brake Brake fault Defective brake Check brake (e.g. Bowden cable) Severe fault caused by controller, hand control Emergency stop Contact specialist dealer device and / or drive motor malfunction Tab. 10  Fault notifications on the control panel / LCD display Ottobock | 91 Skippi Plus...
  • Page 92: Fault Indication: Attendant Control

    Contact specialist dealer ware Joystick is not in the home position Move the joystick to the home Red is flashing 4 x Joystick warning when the unit is turned on position before turning the unit on Ottobock Skippi Plus |...
  • Page 93 Contact specialist dealer 2 LEDs below seat Seat height adjustment are flashing motor fault Backrest / seat Electric seat function Overheating due to excessive load Cool down phase LED is flashing temperature warning Tab. 11  Attendant control fault notifications Ottobock | 93 Skippi Plus...
  • Page 94: Defect/Failure

    1 x every six months. CAUTION Uncontrolled driving behaviour, unexpected sounds or odours. Falling, tipping, collision with persons or nearby objects due to defects. Ottobock Skippi Plus |...
  • Page 95: Maintenance Intervals

    Use the online spare parts catalogue on the Ottobock website ("Customers & Technicians" category) to order spare parts. Only spare parts from Ottobock may be used. Failure to comply will render the warranty null and void. Ottobock | 95 Skippi Plus...
  • Page 96 Battery charger does not show any error messages Electronics via the LEDs Check plug connections Activate brake lever while control unit is switched on Brake Check that the brake function is active when the brake is engaged Ottobock Skippi Plus |...
  • Page 97 Check functionality of the belt buckle Seat attachment Check whether mounting screws are fastened properly Gas compression Visual inspection for scratches on the piston rod and spring (option) or oil leakage actuator Tab. 12 Maintenance measures and intervals Ottobock | 97 Skippi Plus...
  • Page 98: Replace The Fuses

    Avoid parking the wheelchair outdoors whenever possible. The tyres should be replaced every 2 years regardless of wear and tear. If the wheelchair is parked for an extended period of time or the tyres overheat (e.g. in the vicinity of Ottobock Skippi Plus |...
  • Page 99 8 Allen key 2. The defective wheel is now freely accessible and can be and pull the two parts of the rim apart. replaced. 4. The defective inner tube is now freely accessible and can be replaced. Ottobock | 99 Skippi Plus...
  • Page 100: Replacing A Defective Bulb

    4. Turn the defective bulb slightly to unlock it, then remove INFORMATION 5. Grasp the new bulb with a cloth, set it into the socket, Lamp housings and lamps can both be ordered from the and lock it in place (see fig. 56). specialist dealer. Ottobock Skippi Plus |...
  • Page 101: Cleaning And Care

    The rear LED light (see fig. 50) is maintenance-free. If re- The control panel, battery charger, armrest and trim compo- pairs are required, the qualified personnel who fitted the nents can be cleaned with a damp cloth and mild cleaning wheelchair can help. solution. Ottobock | 101 Skippi Plus...
  • Page 102: Disinfection

    Return defective batteries (battery pack) to your specialist dealer when purchasing new ones. 10.2 Information on re-use The power wheelchair is suitable for re-use. Similar to second-hand machines or cars, products that are Ottobock Skippi Plus |...
  • Page 103: Legal Information

    The service manual includes a service schedule for each model, detailed information, and a list of the required tools. Ottobock | 103 Skippi Plus...
  • Page 104: Liability

    The product meets the requirements under the RoHS Direc- tive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of cer- tain hazardous substances in electrical and electronic equipment. Ottobock Skippi Plus |...
  • Page 105: Annexes

    350/400/420/440/460 mm / 13.8"/15.7"/16.5"/17.3"/18.1" Back angle Manually, in 10° increments: -9°/1°/11°/21° oder 0°/10°/20°/30° Back angle adjustment Electric: adjustable by up to 25° Mechanical: adjustable by up to 20° Seat tilt Electric: adjustable by up to 20° Ottobock | 105 Skippi Plus...
  • Page 106 Side panel: < 1 kg (2.2 lbs) Footrest (standard equipment): approx. 1 kg (2.2 lbs) Footrest mechanical swivel-up: 1.8 kg (4 lbs) Battery removable: approx. 11 kg (24 lbs) (per piece) Maximum load capacity 50 kg / 110 lbs (patient weight) Ottobock Skippi Plus |...
  • Page 107 For more information, see the included battery charger instructions for use Driving data Speed 6.0 km/h [3.7 mph]; 7.2 km/h [4.4 mph] (see nameplate for precise information) Maximum safe inclination Climbing ability****: 7° (12 %) Ottobock | 107 Skippi Plus...
  • Page 108 “Range“ in the instructions for use (user). ****** The braking distance can be correspondingly longer due to user weight, installed options and condition of the tyres, and due to weather and sur- face conditions. Technical changes reserved. Tab. 13 Technical data Ottobock Skippi Plus |...
  • Page 109: Threshold Values For Wheelchairs Transportable By Train

    1375 mm (54.1"); including a 1.84 m (72.5") large male wheelchair user (95th percentile) Turning radius 1500 mm (59.1") Maximum weight 300 kg (661 lbs); for wheelchair and user, including baggage Maximum obstacle height that can 50 mm (2") be overcome Ground clearance 60 mm (2.4"); at an upward slope angle of 10°, ground clearance must measure at least 60 mm (2.4") under the footrest for going forward at the end of the slope Maximum inclination angle on 6° (dynamic stability in all directions) which the wheelchair will remain 9° (static stability in all directions, also when wheel lock engaged) stable Tab. 14 Threshold values Ottobock | 109 Skippi Plus...
