  • Page 1 Skippi Service Manual...

  • Page 3: Table Of Contents

    Skippi power wheelchair service manual Page Contents 1 General information ......................5 1.1 Foreword .........................5 1.2 Overview .........................6 2 Safety instructions ......................7 2.1 Explanation of symbols ..................7 2.2 Standards and directives ..................7 2.3 General safety instructions ..................7 2.4 Safety instructions for the use of tools and accessories ........8 2.5 Safety instructions for maintenance work .............9...
  • Page 4 8.4.18 Custom Battery ......................62 8.4.19 Monitor Menu ......................62 9 Delivery ...........................64 9.1 Final inspection ....................64 9.2 Record of delivery ....................65 10 Maintenance schedule ....................66 11 Appendices ........................68 11.1 Technical data .....................68 11.2 Torque values of the screw connections ............68 4 | Ottobock Skippi...

  • Page 5: General Information

    Please use these documents together. • Use the maintenance schedule (checklist) as a template for making copies. Retain com- pleted maintenance schedules and provide the customer with a copy. Instructions for use Skippi 647G57=* Skippi Ottobock | 5...

  • Page 6: Overview

    General information 1.2 Overview Fig. 1 Overview 1 Standard back 6 Caster wheel 2 Side panel 7 Motor 3 Standard seat 8 Drive wheel 4 Brake lever 9 Frame 5 Footrest 10 Control panel 6 | Ottobock Skippi...

  • Page 7: Safety Instructions

    European Union. In other countries, compliance with the applicable laws and national regulations is required. The power wheelchair has been constructed using state-of-the-art technology and is safe to operate. The safety of the Skippi power wheelchair has been confirmed by CE certification and the declaration of conformity. 2.3 General safety instructions INFORMATION Regular maintenance is important.

  • Page 8: Safety Instructions For The Use Of Tools And Accessories

    When using a lifting platform, make sure the power wheelchair is centred on the platform and no parts (e.g. anti-tipper) are protruding into the danger zone. 8 | Ottobock Skippi...

  • Page 9: Safety Instructions For Maintenance Work

    If new screws or nuts with a thread lock are not available, apply a medium-strength liquid thread locking compound (such as Loctite® 241 or Euro Lock A24.20) to the existing screws. NOTICE Risk of damage to the padding. The upholstery must be adequately protected against mechanical and chemical damage during all work on the seat. The backrest and seat bottom are flame retar- dant but nevertheless flammable. They must not come into contact with open flames or embers. Skippi Ottobock | 9...

  • Page 10: Safety Instructions For Maintenance Work On Electrical Components

    Damage to the battery charger. Prevent overheating of the charger during the charging process. Ensure that the cooling fins on the back of the device are not covered. INFORMATION During extended periods of disuse or shipment of the power wheelchair, remove the fuse from the fuse holder to prevent deep discharge of the batteries due to standby consumption. 10 | Ottobock Skippi...

  • Page 11: Effects Of Electromagnetic Interference

    U Because EM energy rapidly becomes more intense as one moves closer to the transmitting antenna (source), the EM fields from handheld radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the po- wer wheelchair's control system while using these devices. This can affect power wheelchair operation and braking. Skippi Ottobock | 11...

  • Page 12: Warnings Regarding Effects Of Electromagnetic Interference

    Despite of compliance with all applicable EMC directives and standards, the power wheelchair can be affected by interference from other electric devices (e.g. department store EAS sy- stems) or cause interference to such devices. If you notice such behaviour, move your power wheelchair outside the interference range. 12 | Ottobock Skippi...

  • Page 13: Interference Resistance Of This Power Wheelchair

    They must not be disposed of with regular domestic waste and the battery acid must not enter the sewage system or penetrate into the ground. The instructions of the battery manufac- turer printed on the batteries must be observed. Skippi Ottobock | 13...

  • Page 14: Transportation And Storage

    Before transporting the power wheelchair, switch off the control unit and engage the brake. You can reduce the size of the power wheelchair for transport by folding down the backrest and removing the side panels and footrests. Fig. 2 Eyebolts, front and rear 14 | Ottobock Skippi...

  • Page 15: Storage

    The manufacturer recommends storing the power wheelchair with slightly elevated tyre pressu- re and using assembly stands or wooden blocks in order to raise the tyres (completely) off the ground in order to protect them from ground frost. Regularly rotating the wheels helps to prevent flat spots. Skippi Ottobock | 15...

  • Page 16: Required Tools And Accessories

    U Tyre lever U Inner tube repair kit U Side-cutting pliers U Water pump pliers, gripping width up to 32 mm U Liquid thread lock, “medium strength” U Handheld programming device U Hoisting device of sufficient capacity U Jack Fig. 3 Tools 16 | Ottobock Skippi...

  • Page 17: Information Display

    For information on errors displayed please see sections 7 and 8. Messages are shown on the control panel display monitor: Display symbol Information Driving menu with speed level and battery ca- pacity Low battery capacity Charging process with drive-away lock Electric back adjustment Electric seat tilt Skippi Ottobock | 17...

  • Page 18: Service Work

    U Check cables for ruptures, signs of wear and proper attachment; replace defective components. U Check cable connections and plug connections. 6.2 Control unit Via the enAble 40 control, the Skippi can show causes of error messages on the display. Er- ror sources in the drive section and in the electric options are indicated by flashing of the cor- responding sections in the display's pictograph.
  • Page 19 The two control panel holders are attached in the same way to the side panel of the Skippi. They are clamped to the underside of the armrest pad with an iron rail.

  • Page 20: Battery Pack/Fuse

    Make sure to have the contacts correctly snap in place when hanging in the battery packs. The contacts are on the underside of the battery packs. The battery packs of the Skippi can be removed easily. Undo the lock, hold the battery packs by the handle and pull up to remove them.
  • Page 21 1. Insert the 3-pin charger plug into the charging receptacle on the control panel. 2. Connect the charger to the power supply network. Charging starts automatically. 3. Disconnect the power supply plug after the charging process is complete. Skippi Ottobock | 21...

  • Page 22: Replacing The Controller

    4. Properly reassemble all components upon completion of the work. 3 4 5 Fig. 8 Controller 1 Connection for control unit 2 Lighting / actuator connector 3 Motor 1 connector 4 Connection for lights 5 Motor 2 connector 22 | Ottobock Skippi...

  • Page 23: Side Panel

    Side panel mounting brackets are located on the left and right sides of the seat frame. By loosening the two set screws which are located on the underside, you can change the posi- tion of the side panel. Afterwards, retighten the set screws using a size 3 Allen wrench. Skippi Ottobock | 23...
  • Page 24 Fig. 12 Underside of the armrest and Changing the position Lateral pads The lateral pad is attached to the side panel with a hook and loop closure. 24 | Ottobock Skippi...

  • Page 25: Seat

    Service Work 6.6 Seat Both, the seat depth and seat width of the Skippi seat can be individually adapted to the child. Adjusting the seat width The side panels are used to set the seat width (see section 6.5 Side Panel). There are two countersunk head screws on each side panel attachment device, below the seat surface.
  • Page 26 Once you have loosened all connections, you can remove the seat. Lap belt The lap belt of the Skippi is/must be attached to the bearing plate. For attachment, an attach- ment plate with eyelet is used. The mounting kit of the lap belt also includes spacer bushings.

  • Page 27: Back

    6.7 Back The back of the Skippi is attached to the seat frame with two bearing plates on the left and right. Each of the two bearing plates is attached to the seat frame with two screws and to the back with one screw.

  • Page 28: Footrests

    Ensure that the telescoping tubes of both footrests are set equally. Use a folding ruler, if nec- essary. The angle of the footplate can be changed by loosening the attachment screw on the front of the footrest bar. Again, you need a size 5 Allen wrench. 28 | Ottobock Skippi...
  • Page 29 Setting the angle Make sure to firmly retighten the screw connections after all adjustments. Telescoping the footrest receivers The footrest receivers of the Skippi can be telescoped in transverse direction independently from each other. Each side can be telescoped outwards continuously by 60 mm/2,4”. For set- ting the footrest receivers, you first have to loosen one of the two screws at the front of the seat frame using a size 5 Allen wrench.

  • Page 30: Electric Seat Tilt

    Service Work 6.9 Electric seat tilt The electric seat tilt can be added to the Skippi at any time. First remove the manual seat tilt mechanism. Fold away the securing bow and pull the bolt out of the respective bore hole (see section 6.6). Then unscrew the seat angle adjustment mecha- nism from the upper attachment, below the seat plate, using two size 5 Allen wrenches.

  • Page 31: Retrofitting The Seat Height Adjustment (Optional)

    It is possible at any time to add a seat height adjustment (lift seat) or a combination of seat height adjustment/ seat tilt or seat height adjustment/ back angle adjustment to the Skippi power wheelchair.
  • Page 32 Here you need a size 6 Allen wrench. 5. Before you are able to install the adjustment motor, you have to fix the holding device to the base frame with six oval head screws with Allen head (see item E). Here you need a size 5 Allen wrench. Fig. 26 Installed retaining bar for the controller 32 | Ottobock Skippi...
  • Page 33 1 mm/0,04“. A distance of 1 – 3 mm/0,04“ – 0,12“ is ideal. It is adjusted by turning the set screw on the magnetic pin. Connect the cable of the magnetic transmitter to the main cable (see item L). Skippi Ottobock | 33...

  • Page 34: Programming

    Controller with connected main cable and Charging and programming receptacle 6.11.1 Programming To be able to use the lift seat, it is first necessary to programme the control unit: 1. Connect the handheld programming device to the charging and programming receptacle of the hand control device (see item N). 2. Follow the menu tree: P rogram > Motor Controller > Multi-Function Input 3 3. Here make the following speed limit settings (speed with raised lift seat): 34 | Ottobock Skippi...
  • Page 35 Signification: Varies the speed (PWM) of actuator 2 (back angle adjustment, seat tilt). Actuator 2 Stop Current 0–12 A Set value to 2 A. Actuator 2 Stop Current Signification: The driver turns off if the current ex- ceeds this value. Skippi Ottobock | 35...

  • Page 36: Drive Unit

    6.13 Motors Each motor of the Skippi has a red brake lever. To unlock the brakes, these have to be pushed outwards which means that the brakes are released and that the Skippi can be pushed. This is also indicated on the display when switching on the wheelchair control.
  • Page 37 – Tighten the motor mounting carriage screws to a torque of 8.4 Nm. – Tighten the screw that attaches the drive wheel with a torque of 25 Nm. NOTICE Damage to the cables. Make sure that cables will not be pinched or damaged during mounting and disassembly. Skippi Ottobock | 37...

  • Page 38: Tyres

    Always change the tyres in pairs. Tyres with differently worn treads can negatively affect the driving characteristics of the wheelchair. For changing tyres, place the Skippi on a level surface and support it to prevent it tilting or falling over.

  • Page 39: Options

    The rear lights are attached to the rear side of the drive unit sustainer with two holders. The holders are attached with two oval head screws. These screws are put through from the inside to the outside and secured with two lock nuts. Skippi Ottobock | 39...
  • Page 40 Properly reassemble all components upon termination of the work. During installation of the lamps, ensure that the lug on the lamp engages in the notch on the socket. Ensure the glass covers are seated properly in the housing when installing them. Tighten the screws on the glass cover firmly so that moisture cannot penetrate into the lamp. 40 | Ottobock Skippi...
  • Page 41 You need a size 6 Allen wrench for this work. Fig. 39 Fastening the tube clamps to the back tube and Fastening the back strap Now you can insert the push handles into the clamp holders while pressing the securing pin. Set the push handles to the desired height and fix them with the quick clamping levers. Skippi Ottobock | 41...
  • Page 42 Position the eyelet of the bumper bar on the caster attachment device as shown on the photo. Attach the bumper bar with the supplied screws. Reattach the plastic protective caps to the caster attachment devices. 42 | Ottobock Skippi...
  • Page 43 Joystick accessories To mount joystick accessories, first pull off the upper end of the joystick. A pin is exposed. Here you can mount accessories such as a fork for tetraplegics, a golf ball or a stick etc. Once you have set the accessory onto the pin, secure it by tightening the set screw. Skippi Ottobock | 43...

  • Page 44: Diagnostics

    The saved data can be used to determine future service and maintenance intervals, for example. The following tables shows the different error messages on the control panel display or sepa- rate LCD monitor. 44 | Ottobock Skippi...

  • Page 45: Display Of Errors/Faults

    Wheel lock fault Open wheel lock release / Close wheel lock release; defective wheel lock check wheel lock (e.g. Bowden cable) Emergency stop Severe fault caused by controller, hand control device and / or drive motor malfunction Skippi Ottobock | 45...

  • Page 46: Enable40 Wheelchair Control - Installation And Programming

    The hand programming device can be used to make parameter changes. Fig. 46 Components of the enAble40 wheelchair control 1 Attendant control 2 Hand control device 3 Controller 8.2 Installation and Wiring Fig. 47 Dimensions of the enAble40 wheelchair control 46 | Ottobock Skippi...

  • Page 47: Programming Devices

    8.3.1 Handheld programming device The 1313 handheld programming device is used to configure the connected enAble40 control system. With the programming device, you can adjust and save parameter settings, restore previous settings, perform diagnostics and troubleshooting, and update the system’s software. Skippi Ottobock | 47...
  • Page 48 When navigating within a hierarchical menu, your menu path is shown at the top of the screen. As shown on the main menu screen, the handheld programming device organises its dataset into nine menus: U System info U Parameters 48 | Ottobock Skippi...

  • Page 49: Pc Programming Station (Pcps)

    1314 PC programmer. These programmable param- eters allow the driving characteristics and performance of the vehicle to be adapted to special deployment requirements. Information about the use of the hand programming device can be found in Section 8.1.4. Skippi Ottobock | 49...

  • Page 50: Configuration" Parameter

    8.4.1 “Configuration” Parameter When the “Configuration” parameter is changed, Powerbase stores the parameters of this configuration but the hand programming device does not. This is why you should disconnect and then reconnect the hand programming device after changing the “Configuration” parame- ter, so that the hand programming device can download the new settings. The hand program- ming device only stores the data it downloads when it gets connected. 50 | Ottobock Skippi...

  • Page 51: Mychair" Parameter

    Ensure that you have selected the correct configuration for your wheelchair model: – Parameter 1 = A200 – Parameter 2 = B500 6 km/h – Parameter 3 = B500 10 km/h – Parameter 4 = Skippi 8.4.2 “MyChair” Parameter The “MyChair” parameter allows the selection of Profile 1, Profile 2, or a blend of the profiles with settings that lie between the two profiles. Parameter Allowable...

  • Page 52: Drive Menu

    2 times as fast; a value of 3 makes deceleration 3 times as fast. The value 1 deactivates this parameter. Emergency 60 – 100 % Rate of deceleration when turning off the key-operated switch or in Stop case of an error. 52 | Ottobock Skippi...

  • Page 53: Steer Menu

    Rate of deceleration with which the wheelchair decelerates back to Decel neutral from a turn of the joystick. Turn Softening 0 – 100 % Desensitises the turning response (Turn Accel/Decel) as a function of the current vehicle speed. Skippi Ottobock | 53...

  • Page 54: Hand Controls Menu

    When the parameter is set to 1, the attendant control unit is the master and the hand controller cannot turn off the system. When the parameter is set to 2, the hand controller can turn off the system even if the attendant control unit is turned on. 54 | Ottobock Skippi...

  • Page 55: Speed Mode

    0 – 100 % Speed limit for Speed Mode 9. Attendant Speed 0 – 100 % Speed limit for attendant control, Speed Mode 1. Attendant Speed 0 – 100 % Speed limit for attendant control, Speed Mode 2. Skippi Ottobock | 55...

  • Page 56: Joystick Menu

    0 – 100 % Determines the brightness of the LCD backlight when the head- lights are turned off. Backlight Night 0 – 100 % Determines the brightness of the LCD backlight when the head- lights are turned on. 56 | Ottobock Skippi...

  • Page 57: Charger Inhibit Menu

    The driver turns off if it runs longer than this period of time. Time Actuator 2 Func- 1 – 5 Indicates the component operated by actuator 2 on the display tion (same choice of selections as actuator 1). Skippi Ottobock | 57...

  • Page 58: Lights Menu

    The speed limits using the multi-function inputs work in the same way as the speed modes; they create an interpolation between the respective minimum and maximum parameter pairs of the active profile (Profile 1 or 2). Note that the maximum speed of the power wheelchair is always the lowest of the respective applicable speed limits. Each of the three multi-function inputs has its own programme menu. 58 | Ottobock Skippi...

  • Page 59: Multi-Function Input 1 Menu

    Set to On, actuator 2 is locked in the positive direction. Act 2 Di r– Inhibit On/Off Set to On, actuator 2 is locked in the negative direction. Speed Limit 0-100 % Sets the speed limit when input 2 is active. Skippi Ottobock | 59...

  • Page 60: Multi-Function Input 3 Menu

    Higher values result in higher torque. Comp Speed 0 – 100 % Sets the speed below which Low Speed Comp is activated. Max Motor Volts 20 – 28 V Sets the maximum current that can be applied to the motor. 60 | Ottobock Skippi...

  • Page 61: Motor And Brakes Menu

    1311 monitor menu. The measured value must be used for the System Resistance param- eter described above. After measuring, the Motor Test Mode pa- rameter has to be set back to Off. Skippi Ottobock | 61...

  • Page 62: Custom Battery

    Drive Command -100 – +100 % Requested, normalised (to 100%) Y-axis value of the joystick, including the deadband. Turn Command -100 – +100 % Requested, normalised (to 100%) X-axis value of the joystick, including the deadband. 62 | Ottobock Skippi...
  • Page 63 System 0 –600 mΩ System resistance as measured by the Powerbase on ter- Resistance minals M1 and M2. This variable only supplies an accurate value if it was measured with the Motor Test Mode parameter set to On. Skippi Ottobock | 63...

  • Page 64: Delivery

    Only for combination of the power wheelchair with products of other ma- nufacturers: Was all information in the instructions for use and installation and service manuals of other manufacturers observed? Only for combination of the power wheelchair with products of other manuf- acturers: Were the instructions for use for new add-ons provided to the user? 64 | Ottobock Skippi...

  • Page 65: Record Of Delivery

    • Provide the user or attendant with a copy of the completed record of delivery. The user or attendant has been instructed in the use of the product and was informed of the residual risks. Customer: Year of manufacture: Serial no.: The product was delivered by: Place / date: Signature of specialist dealer: Signature of user/attendant: Skippi Ottobock | 65...

  • Page 66: Maintenance Schedule

    • Provide the user or attendant with a copy of the completed maintenance report. Customer: Reuse Year of manufacture: Serial no.: Skippi – general condition: Driving report: Areas For all the components listed here check the functioning, setting and screw connections and look for signs of damage or deformation! In good...
  • Page 67 Electric seat tilt Electric seat height adjustment Mechanical seat tilt Push handles 7 Side panel Brackets Clothing protector 8 Footrests Brackets Elevating footrest 9 Options Belt Adapter for headrest Heel straps Comments: Maintenance performed by: Place / Date: Signature: Skippi Ottobock | 67...

  • Page 68: Appendices

    All technical data are found in the 647G59=* instructions for use. You can request current in- structions for use as a PDF file from the Customer Care Center (CCC) at oa@ottobock.com or from the manufacturer’s service department (see inside back cover or back page for ad- dresses). 11.2 Torque values of the screw connections Unless otherwise specified, screw connections are tightened with the following torque values: – Thread diameter M4: 3 Nm – Thread diameter M5: 5 Nm – Thread diameter M6: 10 Nm – Thread diameter M8: 25 Nm 68 | Ottobock Skippi...
  • Page 69 Skippi Ottobock | 69...
  • Page 70 70 | Ottobock Skippi...
  • Page 71 · www.ottobock.com.co Russian Federation Otto Bock Healthcare Products GmbH Otto Bock de Mexico S.A. de C.V. T +7 495 564 8360 · F +7 495 564 8363 Brehmstraße 16 · 1110 Wien · Austria Prolongación Calle 18 No. 178-A info@ottobock.ru ·...
  • Page 72 Ihr Fachhändler/Your specialist dealer: Otto Bock Mobility Solutions GmbH Lindenstraße 13 · 07426 Königsee-Rottenbach/Germany www.ottobock.com...
