Table 4. General-Purpose Port Connector J6* (Continued)
Signal Pin #
PC[7:0] 39,41,43,
45,47,49,
51,53
ID_[2:0] 6,8,10
CON_DIS 12
Reserved 16,18
PD[7:0] 22,24,26,
28,30,32,
34,36
PB[7:0] 40,42,44,
46,48,50,
52,54
Note: *All of the signals are driven directly by the CPU.
Operational Description
Function Direction
Port C, Bit [7:0] Bidirectional
®
eZ80 Output
Development
Platform ID
Console Disable Input
Port D, Bit[7:0] Bidirectional
Port B, Bit[7:0] Bidirectional
PRELIMINARY
Notes
If a shunt is installed between
pins 12 and 14, the Console
function on the eZ80
Development Platform is
disabled.
