eZ80L92 Development Kit
User Manual
80
// This PAL generates signals that control Expansion Module
// access, LED and the general-purpose port.
// This device is a GAL22LV10-5JC (5ns tpd) or equivalent with
// Package = 28 pin PLCC
//
//
module l92_em_pal(
nDIS_EM,
nEM_EN,
A0,
A1,
A2,
A3,
A4,
A5,
A6,
A7,
nRD,
nCS,
nWR,
nMEMRQ,
nIORQ,
nEM_RD,
nEM_WR,
nAN_WR,
nCT_WR,
nDIS_ETH
);
input
nEM_EN
A0
A1
A2
A3
A4
General Array Logic Equations
nDIS_EM /* synthesis loc="P3"*/,
/* synthesis loc="P4"*/,
/* synthesis loc="P5"*/,
/* synthesis loc="P6"*/,
/* synthesis loc="P10"*/,
/* synthesis loc="P11"*/,
/* synthesis loc="P12"*/,
PRELIMINARY UM012906-0103
