eZ80L92 Development Kit
User Manual
44

eZ80L92 Module

Functional Description

Physical Dimensions

Functional Description
This section describes the eZ80L92 Module hardware, its interfaces and
key components, including the CPU, Ethernet Media Access Control, and
memory.
The eZ80L92 Module is a compact, high-performance Ethernet module
specially designed for the rapid development and deployment of embed-
ded systems requiring control and Internet/Intranet connectivity via
Ethernet and/or IrDA. Additional devices such as serial ports, LED matri-
ces, general-purpose port, and I
®
to the eZ80 Development Platform. A block diagram representing both
of these boards is shown in
The eZ80L92 Module is developed to be a plug-in module to the
Development Platform. This small-footprint module provides a CPU,
RAM, Flash memory, an IrDA transceiver, and an Ethernet Media Access
Controller (EMAC). This low-cost, expandable module is powered by the
eZ80L92 microprocessor, a member of ZILOG's new eZ80
family. The module also contains a battery and an oscillator in support of
the on-chip Real-Time Clock (RTC). The eZ80L92 Module can also be
used as a stand-alone development tool when provided with an external
power source.
The dimensions of the eZ80L92 Module PCB is 64x64mm. With an RJ-
45 Ethernet connector, the overall height is 25mm. See Figure 11.
2
C devices are supported when connected
Figure 1 on page 4.
PRELIMINARY
®
eZ80
®
product
UM012906-0103
