eZ80 Development Platform
®
This section describes the eZ80
components and its interfaces, including detailed programmer interface
information such as memory maps, register definitions, and interrupt
usage.

Functional Description

The eZ80
blocks. These blocks, listed below, are diagrammed in Figure 4.
•
•
•
•
•
•
•
UM012906-0103
®
Development Platform consists of seven major hardware
eZ80L92 Module interface (2 female headers)
Power supply for the eZ80
Module, and application modules
Application Module interface (2 male headers)
General-Purpose Port and LED matrix
RS232 serial communications ports
Embedded modem interface
2
I C devices
PRELIMINARY
eZ80L92 Development Kit
®
Development Platform hardware, its key
®
Development Platform, the eZ80L92
User Manual
Functional Description
7
