C.6 Modules
Model
55000-809 XP95 Switch monitor plus
55000-810 XP95 Switch monitor
55000-813 XP95 Zone monitor
55000-818 XP95 Input/Output module
55000-819 XP95 Output module
55000-823 XP95 Sounder control unit
55000-875 XP95 Mains switch input/output
55000-832 XP95 Mini switch monitor (interrupt)
55000-833 XP95 Mini switch monitor (interrupt)
59000-810 XPlorer Output unit
59000-820 XPlorer Switch monitor
C.7 DIN rail modules
Model
55000-803 XP95 DIN rail input/output unit
55000-804 XP95 DIN rail input/output unit
55000-821 XP95 DIN rail switch monitor plus
55000-822 XP95 DIN rail switch monitor plus
55000-812 XP95 DIN rail zone monitor (with isolator)
55000-826 XP95 DIN rail sounder control unit
55000-802 XP95 DIN rail dual isolator
C.8 Modules with isolators
Model
55000-841 XP95 Switch monitor plus with isolator
55000-843 XP95 Switch monitor with isolator
55000-845 XP95 Zone monitor with isolator
55000-847 XP95 input/output module with isolator
55000-849 XP95 Output unit with isolator
55000-852 XP95 Sounder control unit with isolator
C.9 Configuring Apollo devices
Every Apollo device requires an address to identify it on the loop. Apollo devices must be addressed
manually, as follows.
C.9.1 Addressing Apollo detectors
You can address Apollo detectors using the incorporated Xpert cards.
Work carefully through the following steps:
Apollo Devices
Name
Name
Name
DIN rail mount module with 1 delayed input and reset output for waterflow
detectors (waterflow alarm)
Single input module with isolator
Interface module with isolator for conventional zones
Module with 1 relay output + 1 supervised input + 1 non-supervised input
(opto-isolated)
Module with 2 relay outputs with isolator
Single output module with isolator for self-powered sounder control
Description
Module with 1 input with delay and reset output for waterflow
detectors (waterflow alarm)
Single input module
Conventional detector interface module
Module with 1 relay output + 1 supervised input + 1 non-
supervised input
Module with 1 relay output
Module with 1 output for externally-powered sounder control
Module with 1 supervised input + 1 relay x 220V
Reduced-size input module (interrupt)
Reduced-size input module
XPlorer non-supervised output module
Supervised input module
Description
DIN rail mount module with 1 input + 1 output
DIN rail mount module with 1 output
DIN rail mount module with 1 delayed input and reset output
for waterflow detectors (waterflow alarm)
DIN rail mount module with 1 output
DIN rail mount interface module for conventional zones (with
isolator)
DIN rail mount module with 1 output for externally-powered
sounder-control
DIN rail mount dual isolator
Description
