Installation manual
4.4

Technical specifications

Operating voltage
Max current draw on AC input
Internal power supply output voltage
Internal Power supply MAX current
Internal Power Supply output ripple
Max current available for the external load (loop devices, external
loads, attachment boards, etc.)
Minimum current (I
min
Low Voltage range
Panel Current draw (motherboard+LCD screen on the frontplate)
- standby
- from battery in the event of mains failure
- maximum battery-charge current
Battery specifications
(Brand and type)
Maximum internal resistance of the batteries (R
Operating temperature
Dimensions (Height x Length x Depth)
Weight without battery
Attachment board current draw
SmartLoop/2L (2 Loop expansion board)
SmartLoop/INOUT (6 input/output expansion board)
SmartLoop/NET (Token-ring network adaptor board)
SmartLoop/PSTN (PSTN dialler)
SmartLAN (Ethernet board)
SmartLoop/LED (48 LED board)
SmartLoop/PRN (on-panel thermal printer)
SmartLetUSee/LCD (LCD repeater)
SmartLetUSee/LED (LED repeater)
Absolute maximum terminal ratings
Technical description
)
230 Vac -15% + 10% 50/60Hz
0.9 A @ 230Vac
27.6 Vdc
4 A
MAX 1%
2.8 A
600 mA
18 ... 27.6 Vdc
200mA
80 mA
1A
12 V @ 7Ah or 12 V @ 17Ah
YUASHA (or equivalent)
NP 7 -12 FR or NP 17 -12-FR or similar
Flame Class UL94-V2 or higher
) 2.2 Ohm
i max
From -5° to +40° C
48 x 47 x 13.5 cm
8 Kg
stby: 20mA MAX:70mA
stby:40mA MAX:300mA
stby: 40mA MAX:40mA
stby:20mA MAX:60mA
stby:200mA MAX:200mA
stby:40mA MAX:80mA
stby:0 MAX:1A
stby: 40mA MAX:50mA
stby: 5mA MAX:50mA
19
