Argus Devices
Note:
The ARGUS devices accepted by this control panel do not have IMQ-SECURITY SYSTEMS certification, refer
to the instructions leaflet provided with each device.
All Argus Vega devices have built-in loop isolators. Therefore, isolators are not required. A short-circuit on
the loop will not provoke loss of any device.
Each detector is equipped with a 3-colour LED: green (periodic blinking) indicates the detector is working
properly (if enabled). Yellow indicates that the detector is not operating properly (fault) or has an open
isolator, whereas red indicates alarm status.
Detectors are equipped with test LEDs: if you hold a magnet near the detector base (near to the two
notches) the detector should generate an alarm signal.
B.1 Devices
Model
V100 Analogue optical detector
V200 Analogue Multicriteria detector
V350 Analogue temperature detector
VCP100 Intelligent resettable callpoint
VWCP100 Weatherproof intelligent resettable callpoint Callpoint with resettable mechanism for outdoor installation
VMI100 Input module
VMMI100 Input Minimodule
VMDI100 DIN rail input module
VUMI100 Input Micromodule
VMC100 Output Module
VMMC100 Output Mini Module
VMDC100 DIN rail output module
VUMC100 Output Micromodule
VMC120 Output Module Form C
VMMC120 Output Mini Module Form C
VMDC120 DIN rail output module Form C
VUMC140 Output Micromodule Form C
VMIC100 Input/Output Module
VMMIC100 Input/Output Mini Module
VMDIC100 DIN rail Input/Output module
VMIC120 Input/Output Module Form C
VMMIC120 Input/Output Mini Module Form C
VMDIC120 DIN rail Input/Output module Form C
Argus Devices
Name
Optical smoke detector
Optical smoke&heat detector
Heat detector (
Callpoint with resettable mechanism
Module with 1 supervised input
Reduced-size module with 1 supervised input
DIN rail module with 1 supervised input
Reduced-size module with 1 supervised input
Module with 1 Supervised Output
Reduced-size module with 1 supervised output
DIN rail module with 1 supervised output
Reduced-size module with 1 supervised output
Module with 1 voltage-free output (non-supervised)
Reduced-size module with 1 voltage-free output (non-supervised)
DIN rail module with 1 voltage free relay (non-supervised)
Reduced-size module with 1 voltage-free output (non-supervised)
Module with 1 supervised input + 1 supervised output
Reduced-size module with 1 supervised input + 1 supervised output
DIN rail module with 1 supervised input + 1 supervised output
Module with 1 supervised input + 1 non-supervised output (voltage-
free contact)
Reduced-size module with 1 supervised input + 1 non-supervised
output (voltage-free contact)
DIN rail module with 1 supervised input + 1 non-supervised output
(voltage-free contact)
Description
a
)
