INIM SmartLoop Series Installation Manual page 50

VMCZ100 Conventional-line interface module
VMIC404 Module with 4 inputs + 4 outputs
VLS100 Intelligent Wall Sounder
VWLS100 Weatherproof Intelligent Wall Sounder
VLS100-AV Intelligent Wall Sounderflasher
VWLS100-AV Weatherproof intelligent Wall Sounderflasher
VLBE100 Intelligent Flasher
VTAO10 Sounderflasher fire sign
VTAOA10 Self-powered Sounderflasher Fire Sign
VFI100 Intelligent Remote Indicator
VPU100 Programmer
a. Configured as "Rate-of-rise detector" at default (alarm is triggered by rapid rise in temperature or when the temperature
exceeds the 54°C alarm threshold). To configure as "High temperature detector" (Rate-of-rise feature bypassed and fixed
temperature set at 70°C) use the VPU100 programmer. The panel will recognize the configuration criteria automatically.
B.2 Device Bases
Model
VB100 Base
VDBS100 Deep Base
BLR100 Relay Base
VBS100 Base with sounder
VBLS100 Base with addressable sounder
B.3 Wireless devices
Model
VW2W Wireless Translator
SGWE Wireless Expansion
SG100 Wireless Analogue Optical Smoke Detector
SG200 Wireless Analogue Optical Smoke/Heat Detector
SG350 Wireless Temperature Detector
SGRBS100 Wireless base sounder
SGRBS100-AV Wireless base sounder with beacon
SGMI100 Wireless input module
SGMC100 Wireless output module
SGMCB100 Wireless module with 2 outputs
SGCP100 Wireless callpoint
SGRS100 Wireless sounder
SGVA100 Wireless voice announcer
SGFI100 Wireless addressable remote alarm repeater
a. Configured as "Rate-of-rise detector" at default (alarm is triggered by rapid rise in temperature or when the temperature
exceeds the 54°C alarm threshold). To configure as "High temperature detector" ( Rate-of-rise feature bypassed and fixed
temperature set at 70°C) use the VPU100 programmer. The panel will recognize the configuration criteria automatically.
50
Interfaces conventional devices to the loop
Module with 4 supervised inputs + 4 outputs (dry contact)
Loop-powered sounder (wall mount)
Loop-powered sounder for outdoor installation
Loop-powered sounderflasher (wall mount)
Loop-powered sounder for outdoor installation (wall mount)
Loop-powered beacon
Visual/Audible fire sign with input/output module
Self-powered visual/audible fire sign with input/output module
Remote addressable alarm repeater
Allows fast addressing of Argus series devices
Name
Standard base for VEGA detectors
Allows connection to wall-mount cable runs
Relay activated by the detector R output attached to the base
Activated by the detector R output attached to the base
This device occupies a loop address
Name
Description
Description
Connected to Loop, 32-device interface (Sagittarius series -
SG) wireless to panel
The control panel sees the 32 devices as loop-connected
devices with different addresses
a
( )
Installation manual
Argus Devices
