Enea devices
All devices in INIM's new Enea series of addressable-analogue detection
devices are LPCB certified and carry the CE mark according to CPD.
Each device is equipped with a short-circuit isolator which, in the event
of short-circuit between two control-panel (loop) connection wires, is capable of interrupting the negative
wire and isolating the wire section concerned. Up to 240 devices can be connected. Each device is identified
by a factory-assigned serial number which allows automatic addressing.
INIM's Enea series provides three analogue detector models:
• Optical chamber with sealed upper-part and 500 micron hole-diameter mesh insect screen
• Three-colour LED - Red for alarm, Green flash for standby and for identification from the control panel;
Yellow for fault status
• Supervised remote output configurable from the control panel
• Automatic recognition of remote signaller connection
• Drift compensation for sensor drift caused by dust in the chamber
• Sensitivity selection for smoke and heat thresholds
• Operating mode selection (for ED300 version) - Only smoke; Only heat
• AND mode, OR mode, PLUS mode
• Complete diagnostics - provides contamination level and real-time values
• Memory of the smoke and temperature levels measured in the five-minute period prior to the last alarm
detected
• Bypass plate on base guarantees continuity in the event of removal of the detector from the line
For further details regarding the precise features and technical specification of each device, refer to the
respective instructions booklet.
Type
Detectors
Bases
Modules
Manual
callpoint
LED
46
Model
ED100 Optical smoke detector
ED200 Heat detector
ED300 Heat and smoke detector
EB0010 Mounting base
EB0020 Relay base
ESB010 Base sounder (to be installed under an EB0010 base)
ESB020 Base sounder and beacon (to be installed under an EB0010 base)
EM312SR Input/Output module
EM110 Input module
EM311 Micromodule
EM344S Conventional zone interface module with 4 inputs + 4 outputs
EC0010 Manual callpoint
EC0010E Weatherproof manual callpoint for outdoor installation (IP67)
FI100 Addressable remote alarm repeater
Description
