Table Of Contents - INIM SmartLoop Series Installation Manual

Installation manual

Table of contents

Copyright ............................................................................ 2
European directive compliance ............................................... 2
Table of contents.................................................................. 3
Chapter 1 Introduction......................................................................... 5
1.1 Application and use 5
1.2 Other parts of the system 7
1.3 In order to validate the IMQ-SECURITY SYSTEMS certification, and in compliance
with EN54-2 regulations: 8
1.4 About the SmartLoop fire alarm panel series 8
1.5 Description of the models 8
1.6 Features 9
Chapter 2 General information ............................................................ 10
2.1 Documentation supplied 10
2.2 Manual details 10
2.3 Firmware information 10
2.4 Operator classification - Access Levels 10
2.5 Intellectual property rights 11
2.6 Disclaimer 11
2.7 Recommendations 11
2.8 Testing the system 11
2.9 Note to the installer 11
2.10 Technical support 11
2.11 Conventions 11
2.12 Device identification details 12
2.13 Warranty 13
2.14 Safety laws 13
Chapter 3 Device management ........................................................... 15
3.1 Product handling and storage 15
3.2 Environmental conditions 15
3.3 Unpacking the device 15
Chapter 4 Technical description........................................................... 16
4.1 Panel 16
4.2 The motherboard 16
4.3 LED panel 18
4.4 Technical specifications 19
Chapter 5 Accessory devices............................................................... 21
5.1 Attachment boards 21
5.2 SmartLoop/PRN Printer 25
5.3 The SmartLetUSee/LCD and SmartLetUSee/LED Repeater panels 26
Chapter 6 Installation ........................................................................ 27
6.1 Choosing the mounting location 27
6.2 Installation flow, guidelines and testing 27
6.3 Connecting the SmartLoop/PRN printer module 28
Chapter 7 Connections....................................................................... 29
7.1 Note to the Installer regarding wiring and connection compliancy 29
7.2 About the circuitry 29
7.3 Loop Connections 29
7.4 NAC Outputs (Notification Application Circuit) 32
7.5 PL Terminal 32
7.6 AUX output 33
7.7 AUX-R output 33
Table of contents 3
