  • Page 1 Certified by IMQ - Security systems CEI 79-2 EN 50131-3 EN 50131-6 T014 GameOver I N S T A L L AT I O N MANUALE A N D INSTALLAZIONE P R O G R A M M I N G PROGRAMMAZIONE M A N U A L...

  • Page 2: Warranty

    24 months. As INIM Electronics s.r.l. does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;...

  • Page 3: Table Of Contents

    Installation and Programming Manual Table of contents Warranty ........2 Limited Warranty .
  • Page 4 Installation and Programming Manual Programming via the SmartLeague programme ....42 Panel options ........42 Terminals .

  • Page 5: About This Manual

    Installation and Programming Manual ABOUT THIS MANUAL MANUAL CODE DCMIINE0SLIVINGE VERSION 4.10 Terminology CONTROL PANEL, SYSTEM, The main supervisory unit and any constituent parts of the SmartLiving intrusion control system. APPARATUS LEFT, RIGHT, BEHIND, Directions as seen by the operator when directly in front of the mounted device. ABOVE, BELOW DIALER A device which sends voice calls or digital reports to programmed contact...

  • Page 6: Chapter 1 General Information

    Web: www.inim.biz Any persons authorized by the manufacturer to repair or replace the parts of this system, hold authorization to work on INIM Electronics brand devices only. Description of the product and various models Description: Intrusion control panel...

  • Page 7: Patents Pending

    • S0 Substitution security (no detection of device substitution) • I0 Information security (no detection of message substitution) Patents Pending The SmartLiving series of control panels employs the following INIM-patented technologies. • Input/Output Terminals: each terminal on-board the control panel, JOY keypads and FLEX5 expansion boards can be configured as either an input or output zone (Split terminal technology).

  • Page 8: Manuals

    Installation and Programming Manual Manuals 1-5-1 Installation and Programming Manual (this manual) This Manual (not included in the package) can be purchased from your retailer. You (the installer) should read carefully through it in order to become familiar with all the components and operating procedures of the SmartLiving system. In order to provide adequate protection, the installer must adhere to all the manufacturer's guidelines relating to the active and passive security devices of this system.

  • Page 9: Chapter 2 The Control Panel And Peripherals

    Screws to secure the area frontplate of the metal enclosure “INIM Electronics security-protected area” sticker Items not included in the package: Thermal probe (battery-charge optimizer which operates in accordance with the battery temperature), backup battery, SmartLeague programme CD, Installation Manual.
  • Page 10 Installation and Programming Manual 2-2-2 Control panel descriptions Table 2: Control panels - electrical specifications and mechanical features SmartLiving intrusion control panels 1050 1050L 10100L Power supply voltage 230V -15% +10% 50/60Hz Nominal output voltage 13.8V Voltage - operating range 9 - 16 V Maximum current draw 0.2A...
  • Page 11 Installation and Programming Manual SmartLiving 505/515 Table 4: Control panels - description of parts control-panel motherboard Model 1050 1050L 10100L 5A switching Power adaptor (Transformer) 3A switching power supply power supply Mains connection terminal-board (230 Vac) - 50/60 Hz Power cable - adaptor to control Power cable - switching-power supply to panel panel Power cable - switching-power supply to panel...
  • Page 12 Installation and Programming Manual SmartLiving 505/515 SmartLiving 1050 SmartLiving 10100L The control panel and peripherals...

  • Page 13: Peripherals

    (2 power-supply wire and 2 data exchange wires, refer to paragraph 3-2-1 The I-BUS line wiring). The intellectual property rights regarding the electrical, structural and protocol features of the BUS are the sole property of INIM Electronics s.r.l. The I-BUS is not a RS485 differential BUS. Peripherals The control panel I-BUS accommodates the following peripherals: •...
  • Page 14 Installation and Programming Manual Keypad terminals: Table 8: Joy - terminal board Icon/ description Identifier Terminal “+” for the I-BUS connection Terminal “D” for the I-BUS connection Terminal “S” for the I-BUS connection Terminal “-” for the I-BUS connection Screw terminal of keypad terminal T1 Negative power terminal (Negative or GND) Screw terminal of keypad terminal T2 Negative power terminal (Negative or GND)
  • Page 15 Installation and Programming Manual You can connect Code/G and Concept/G keypads using the connector on the back Mounting bracket of the device, using either the 6 wire cable (included), or the KB100 terminal board included in the deep-bracket kit (accessory kit). 6 wire cable KB100 - terminal board Table 11: Connection cables - KB100 terminal board...
  • Page 16 Installation and Programming Manual 2-3-4 Flex5 expansion boards Flex5/P The Flex5 expansion board enclosure is available in two versions. Flex5/U • Flex5/P comes in the enclosure shown above. This version can be set up to monitor dislodgement and open-enclosure tamper by inserting a jumper into connector [D], as shown.
  • Page 17 • Double zone • Supervised Output 2-3-5 Transceiver for Air2-BS100 The Air2-BS100 two-way wireless system integrates directly with all models of the INIM intrusion control panel range. Description of the Air2 system devices: • Air2–BS100 wireless transceiver module • Air2–IR100 passive infrared detector •...
  • Page 18 Installation and Programming Manual Table 20: Nexus - description of parts Terminal board Antenna connector P1 button P2 button SIM card housing (non included) Buzzer Open-tamper microswitch Communication LED (green) Emergency LED (red) Fault LED (red) Connection LED (green) The terminals for the BUS connection are as follows: Table 21: Nexus terminal board Icon/ description...

  • Page 19: Chapter 3 Installation

    Installation and Programming Manual Chapter 3 INSTALLATION Installing the control panel 3-1-1 Wall-mounting The control panel should be located in a hidden place that can be accessed by authorized building occupants only. 1. Using the backbox (Table 4: Control panels - description of parts, G), mark the anchor screw locations on the wall.
  • Page 20 Installation and Programming Manual AC Input AC Input 230V ~ 50/60 Hz 230V ~ 50/60 Hz SmartLiving10100L SmartLiving 1050 SmartLiving1050L 3-1-3 Maximum current - normative references Compliancy with EN50131, CEI 79 or CEB T014 requires full observation of the rules (relating to the applicable normative and the model of the control panel concerned) presented in the Table below.
  • Page 21 Installation and Programming Manual SmartLiving 505/515 SmartLiving 1050 SmartLiving10100L 3-1-5 Thermal Probe The battery charge process can be optimized by means of a thermal probe [C] (accessory item). This device regulates the charging process in accordance with the battery temperature. The thermal probe protects against battery overheating and consequent permanent damage to the battery.
  • Page 22 If you are installing the system in a place where the land line (PSTN) service is not available, or if you wish to increase the level of security of the system, these terminals also accept a GSM interface (such as Inim's SMARTLINK) which simulates the analogue land-line.
  • Page 23 If you wish to purchase an RS232 serial link, refer to the codes in Appendix H, Order Codes. If your PC is not equipped with an RS232 port, but has a USB instead, you can use INIM's Approved RS232-USB adaptor (accessory item). SmartLiving end...

  • Page 24: Connecting Peripherals

    Installation and Programming Manual 3-1-10 Maintenance status There are two distinct positions for the Service jumper (Table 4: Control panels - description of parts, Q): 1. “RUN” (control panel operating normally) 2. “SERV” (control panel ready for maintenance work) The keypads indicate maintenance status (jumper in “SERV” position) by showing the “Maintenance”...
  • Page 25 Installation and Programming Manual ATTENTION! The shield must be connected to one of the terminals (Negative or GND) at the control panel end only, and must run along the BUS without being connected to negative or GND at any other point. If you wish to increase the length and performance of the BUS, you can connect IB100 isolators .
  • Page 26 Installation and Programming Manual 3-2-3 Installing nCode/G and Concept/G keypads 1. Connecting the device to the system 2. Pull the connection wires through the wire entry [A]. 3. Connect the cables to the connector on the keypad backplate [B]. If you are using the connector provided with the KB100 kit [C], connect the wires to the terminals, in accordance with the instructions described in paragraph 2-3-2 nCode/G and Concept/G Keypads, then insert the connector into the...
  • Page 27 Installation and Programming Manual 1. Ensure that the centre of the cover plate coincides with the crossing of the axes x and y on the drill-pattern. In this way, the two drilling locations (1 x 7mm diameter and 1 x 8mm diameter) will be positioned precisely. 2.

  • Page 28: Addressing The Peripherals

    Installation and Programming Manual Addressing the peripherals In order to allow the control panel to identify the peripherals distinctly, you must assign a different address to each device. However, you can assign the same address to two devices which belong to different categories (e.g. a Flex5 expansion and a JOY keypad) as, in this case, the control panels will see them as two distinct devices.
  • Page 29 Installation and Programming Manual 3-3-1 Addressing the keypads Work carefully through the following steps. k e y p a d a d d r e s s 1. Put the control panel in “Maintenance” mode by inserting the respective jumper (Table 4: Control panels - description of parts, Q). M i n .

  • Page 30: Auto-Enrolling Peripherals

    Installation and Programming Manual 7. If you wish to assign an address to another reader, hold a valid key in the vicinity of the reader and work through points 4 to 6. 8. End the reader-address programming phase (exit “Prog. address” via key- pad, or click on “Stop reader address setup”, if you are using the Smart- League software).
  • Page 31 Installation and Programming Manual 3-5-2 Single balancing Single zones can discriminate 3 conditions on the entire terminal: • standby • alarm • tamper (short-circuit) For each of these, the control panel reads different resistance values on the terminal, expressed below in Ohm. Zone 6K8W W 1/4W >...

  • Page 32: Wiring And Balancing Rollerblind/Shock Sensors

    Installation and Programming Manual 3-5-5 Double Zone balancing with EOL Double zones with EOL resistors can discriminate 6 conditions on the entire terminal: • standby on both zones • alarm on zone 1 and standby on zone 2 • alarm on zone 2 and standby on zone 1 •...

  • Page 33: Connecting Wireless Detectors

    The relay output on the control panel motherboard is the alarm output which is most commonly used to drive a self-powered sounder. The following wiring diagram shows the connection of a self-powered sounder (IVY manufactured by INIM) and an indoor sounder. Installation...

  • Page 34: Attachment Boards

    Installation and Programming Manual Control Self-powered sounderflasher panel Indoor sounderflasher 3-9-2 Connecting open- collector outputs All the system outputs, except for the relay output on the control panel motherboard, are open-collector outputs. • OC1 and OC2 are open-collector outputs that sink maximum currents in accordance with the Table 3: Control panel - Main Features.
  • Page 35 Installation and Programming Manual The activation of each relay is signaled by the on-board LED ([D] for relay 1 and [E] for relay 2). If you intend installing this board, work carefully through the following steps. 1. Disconnect all sources of power to the control panel (Mains 230V a.c and battery power).
  • Page 36 Installation and Programming Manual 3-10-3 Flex5/U The metal enclosures of SmartLiving 1050L and 10100L control panels provide housing for two Flex5/U expansion boards (accessory items). If you intend installing this type of board, work carefully through the following steps. 1. Disconnect all sources of power to the control panel (Mains 230V a.c and battery power).

  • Page 37: Chapter 4 First Power Up

    Installation and Programming Manual Chapter 4 FIRST POWER UP On first power up, the control panel initializes the parameters at default (factory settings). The control panel also enrolls all the peripherals it finds on the I-BUS automatically (automatic addressing phase). The default address of all expansions, keypads and readers is address 1, therefore, if the system is equipped with more than one of each type of device, the automatic enrolling operation will be erroneous.

  • Page 38: Chapter 5 Installation Project Via Smartleague Software

    It is possible to consult FAQ page, make enquiries and suggestions via e-mail. Access to the area reserved for registered users of the INIM website. After typing in a Username and Password, you can access the updated versions of the software programme, firmware, technical documentation and service.

  • Page 39: Using The Software Programme

    Installation and Programming Manual Using the software programme Each project, from the most uncomplicated to the most complex of systems, is represented by a solution, which contains the programming parameters and installation structure. A solution is dedicated to a specific type of apparatus and has its own programming interface.
  • Page 40 Installation and Programming Manual 3. To download the data to the control panel, click-on the key. Download- ing operations will: • Block all system keypads. PROGRAMMING • Broadcast the “PROGRAMMING” message to all the keypads. FROM COMPUTER • Force all the system keypads to standby status. •...

  • Page 41: Chapter 6 Options And Programming Methods

    Installation and Programming Manual Chapter 6 OPTIONS AND PROGRAMMING METHODS Introduction The options, functions and values of the SmartLiving control panel must be programmed by qualified persons only. The SmartLiving control panel is programmed at the factory with almost ready-to-go settings (“default settings”) which require only minor changes during the system customization phase.

  • Page 42: Programming Via The Smartleague Programme

    Note Teleservice. If you wish the control panel to call an installer company number which uses an INIM modem, you must set “None” in the Telephone Number Type field. Options and programming methods...
  • Page 43 Installation and Programming Manual Table 31: Panel options Option If enabled If disabled The control panel will enable the Teleservice function if: • the installer calls the control panel • the control panel detects the ring, picks up, Install.callback recognizes the installer code and hangs up immediately •...

  • Page 44: Terminals

    Installation and Programming Manual Table 31: Panel options Option If enabled If disabled The status of the partitions will be hidden. If a valid code is entered at a keypad, the real-time status will be indicated on the keypad concerned for 30 seconds. If the partitions are armed, the status of the system will be hidden from non-authorized users.
  • Page 45 Installation and Programming Manual Via Keypad PROGRAMMING 1. Access the “Programming Terminals” section. Panel options Type-in Code (Installer PIN) , PROGRAMMING Terminals Terminals Zones The display will show the: 1° riga: the number of terminals 2° line: the type of terminals and the selected terminal 3°...

  • Page 46: Zones

    Installation and Programming Manual Select “SmartLiving System - Terminals” from the tree menu on the left, then go to the “Parameters settings” template on the right: All the terminals will be shown on the respective page. You must configure the terminal graphically using the mouse, as follows: 1.
  • Page 47 Installation and Programming Manual •• if the “View open zones” option is enabled, it will be shown on the keypad •• it will not generate “Partition not ready” events •• On arming from a keypad, the zone will appear as a violated zone but, when the arming operation is confirmed, will behave as a delayed zone and will not generate an alarm.
  • Page 48 Installation and Programming Manual Wireless Note Please note that this section will be operative only when the zone you are working on is configured as a wireless zone (refer to paragraph 6-5 Terminals). This section allows you to carry out all the operations relating to the Wireless programming of Air2 wireless series devices.
  • Page 49 Installation and Programming Manual Alarm cycles This programmable parameter accepts values between 1 and 15. If you set the value at 15, the zone will operate as a “repetitive zone” (refer to Appendix A, Technical terminology and Glossary, Alarm cycles). Detector type It is possible to configure a zone as: •...

  • Page 50: Outputs

    Installation and Programming Manual 1. Use to select whether to indicate the time in multiples of 15 milliseconds, seconds or minutes (see “info” box). 2. Use keys to select the field you wish to change, then use the number keys ( , etc.) to edit the number.

  • Page 51: Telephone

    Installation and Programming Manual Monostable time If this value is This parameter applies to “Monostable” outputs only. This interval can be expressed in minutes, expressed in seconds or minutes (see “info” box). there is an error When a “Monostable” output receives an activation signal, it will remain active margin of 1 minute (for (On) for the programmed time, regardless of the status of the trigger-event.

  • Page 52: Events

    Installation and Programming Manual • Partitions: you can associate each telephone number with specific partitions. By selecting the partitions, using Keys , you enable/disable the users (who have at least one of these partitions in common with the telephone number) to modify the number concerned. Number of rings This value determines the number of rings the system allows before picking up an incoming call.
  • Page 53 Installation and Programming Manual Table 33: Event type Pulse Name Occurs when... Restores when ... Number of events events One event for each Zone alarm A zone generates an alarm A zone restores zone A terminal detects tamper (short-circuit or One event for each Terminal tamper A terminal restores...
  • Page 54 Installation and Programming Manual Table 33: Event type Pulse Name Occurs when... Restores when ... Number of events events The status of all least one of the The status of all the partitions corresponds One event for each Scenario ON partitions does not correspond to the exactly to the pre-set scenario.
  • Page 55 Installation and Programming Manual Via Keypad PROGRAMMING Outputs 1. Accessing the “Events” section Telephone Type-in Code (Installer PIN) , PROGRAMMING Events Events 2. Use keys to select the event type (if you are dealing with a group of events, repeat the operation) then press 3.
  • Page 56 Installation and Programming Manual Option If enabled If disabled When the event occurs, the system will play the event- Local Message ON related voice message on keypad speaker n. 1 When the event occurs, the system will not play the Local MessageOFF event-related voice message on keypad speaker n.
  • Page 57 Installation and Programming Manual Via PC SMS message number/index This option can be programmed solely via the SmartLeague software programme. This option is applies only when a Nexus device is installed and the “Automatic SMS” option is disabled. It determines which of the 50 available SMS messages will be sent (refer to paragraph 6-26-4 Text for SMS messages) when the event occurs.
  • Page 58 Installation and Programming Manual Temporizers A temporizer is a logical expression element (it may have an “active” or “non active” value). It is characterized by an interval, therefore, you must specify an interval (in seconds) for each temporizer you wish to include. You can select up to four “Start events”...

  • Page 59: Timer

    Installation and Programming Manual • Associate the programmable event with the telephone call you wish to receive If you wish to activate a telephone call after 3 consecutive wrong code entries (with a maximum of 120 seconds between each entry). •...

  • Page 60: Partitions

    Installation and Programming Manual The exceptions have priority over the days of the week. For example, If a “timer exception”, lets say 1st May, falls on a Tuesday the settings programmed for 1st May will be applied. Note The “timer exceptions” cannot be programmed via keypad. 6-11 Partitions This programming section deals with the system Partitions and the respective...

  • Page 61: User Codes

    Installation and Programming Manual • Auto-arm STAYmode - if enabled by means of the key, the partition will arm in Stay mode at the pre-set auto-arm time. If disabled by means of , the partition will arm in Away mode at the pre-set auto-arm time. •...
  • Page 62 Installation and Programming Manual • AnnounceShortcut - (for JOY/MAX keypad only) if enabled, after PIN entry followed by , the voice guide will announce the available shortcuts for the user-code concerned and the respective number keys on the keypad. Note Set the “Loc.KpadMess Time”...

  • Page 63: Installer Codes

    Installation and Programming Manual Via PC Select an item from “SmartLiving System - Users - Codes” from the tree menu on the left, then go to the “Parameters settings” template on the right. 6-13 Installer codes This section allows you to programme the functions of the 2 installer codes. The user code PINs must comprise 4, 5 or 6 digits.
  • Page 64 Installation and Programming Manual Key parameters This section allows you to programme all the parameters of the selected digital key. • Description - editable field for the name of the digital key user. • Partitions - the partitions the digital key is assigned to and therefore can control.

  • Page 65: Arming Scenarios

    Installation and Programming Manual 6-15 Arming scenarios This section allows you to configure up to different 30 arming scenarios. PROGRAMMING Via Keypad Installer Code Keys 1. Access “Arming scenarios” section. Arming Scenarios Type-in Code (Installer) , PROGRAMMING Arming scenarios 2. Use keys to select the scenario then press Description Editable field for the description of the scenario.

  • Page 66: Expansions

    Installation and Programming Manual Icon This section allows you to select the icon you wish to represent the scenario, simply by indicating the icon number (refer to Appendix B, Shortcuts at default): 1. Use keys to scroll across the digits. 2.

  • Page 67: Readers

    Installation and Programming Manual “Activate outputs”, this parameter refers to the output that will be deactivated “Deactiv. outputs”, this parameter refers to the output that will be deactivated The “Listen-in” and “Arming status” will have no effect if the respective command is entered at a keypad.

  • Page 68: Sounders

    Installation and Programming Manual Prog. Address This section allows you to activate the enrolling phase and programme the addresses of nBy/S and nBy/X readers. Follow the instructions for addressing readers in paragraph 3-3-3 Addressing nBy readers. Via PC Readers - via SmartLeague software programme Table 39: Option Part of the system...

  • Page 69: Messages

    Installation and Programming Manual 6-22 Messages Record This section allows you to record (and playback) all the voice messages. The Table in the Appendix shows all the pre-recorded messages provided by the 0034 sec. SmartLogos30M voice board. Via Keypad 1. Accessing the “Messages” section: Type-in Code (Installer PIN) , PROGRAMMING Messages 2.
  • Page 70 Installation and Programming Manual 4. Restore the short-circuit condition. Within 70 seconds the control panel will reset to default settings, re-enroll all the peripherals currently on the I-BUS and, if a keypad is connected, will ask you to select the Language. Reset to factory default will not clear the events log.

  • Page 71: User Functions

    Installation and Programming Manual 6-24 User functions This section describes the functions the installer has in common with the user. PROGRAMMING Messages Via Keypad Default settings 1. Access the “User functions” section: User functions Type-in Code (Installer) , PROGRAMMING User functions 2.

  • Page 72: Other Parameters

    Installation and Programming Manual 6-25 Other parameters This option allows you to programme the advanced functions of the control panel. Via Keypad 1. Access the “Other parameters” section. Type-in Code (Installer PIN) , PROGRAMMING Other parameters 2. Use key to select the parameter then press Periodic event This parameter allows you to set the time (hh/mm), day, month and year of the first “Periodic event”...
  • Page 73 Installation and Programming Manual 3. Use key to select the field you wish to change, then use the number keys ( , etc.) to edit the number. Use key to increase or decrease the number. FaultNotReady This section allows you to select which events, other than zones in alarm status, will be signaled as system security-risk conditions when the partition arms.

  • Page 74: Programming The Nexus

    Installation and Programming Manual 6-25-1 Telephone line adjustment The “OverThePhoneVol.” and “Tel. input gain” parameters can be used to correct the voice functions of the dialer and the DTMF tones. The values of these parameters affect each other, therefore, and a good result is always a compromise.
  • Page 75 Installation and Programming Manual •• Inhibit (bypass) control panel zones •• Activate (unbypass) control panel zones • Shortcut option - field for the selection of the parameter relating to the shortcut. • Shortcut 2 - field for the selection of a second shortcut which is to be activated the one selected previously (as above).
  • Page 76 Installation and Programming Manual • “EXC” (or “ESC”), to inhibit the control panel zones • “INC”, to activate the control panel zones For the last two commands, the message text must be: <xxxxxx> EXC <zone description> where: • <xxxxxx> is the PIN of a control-panel user coded, followed by a blank space •...
  • Page 77 Installation and Programming Manual •• Low credit threshold - remaining credit limit, expressed in local currency. If credit drops below this limit, the Nexus dialer will signal “Low credit”. •• Credit enquiry interval - interval, expressed in hours, which must pass between one automatic balance-enquiry and another.

  • Page 78: Chapter 7 Errors And Faults

    Installation and Programming Manual Chapter 7 ERRORS AND FAULTS Faults detected by the control panel The following table shows the system faults which are signaled on the yellow LED on the keypad Message on the User menu, FAULT Probable cause Note “View/Faults”...

  • Page 79: Communication Bus (I-Bus)

    Installation and Programming Manual Sounder faults / Horn A defect/damage has been detected on the horn/ fault sounder. A low-voltage value has been detected on the Press on “Sounder faults” to sounderflasher battery. access the list of devices which Sounderflasher faults If the voltage drops below 10V, the device will have at least one fault present.

  • Page 80: Ring Sensitivity

    Installation and Programming Manual Ring Sensitivity The various configurations of modern telephone lines and the multiplicity of signals that transit along them, require major attention in the design of phone- line interfaces. The optimized phone-line interface on-board SmartLiving control panels has been especially designed to satisfy present day requirements. In addition to the traditional telephone plug for land line (PSTN) connections, there are usually boards for ISDN or ADSL connections.

  • Page 81: Appendix A Technical Terminology And Glossary

    Installation and Programming Manual Appendix A TECHNICAL TERMINOLOGY AND GLOSSARY 24 HOUR ZONE Violation of a zone with this attribute will generate an instant alarm even when the partitions it belongs to are disabled. The system will generate the respective alarms which will be shown on the keypad.
  • Page 82 Installation and Programming Manual This is the secondary power source of the system. If primary (230 Vac) power failure occurs, the BACKUP BATTERY battery will take over. SmartLiving control panels use sealed lead batteries. The battery housing determines the maximum size of the battery and therefore, its power-storage capacity. SmartLiving control panels provide housing for one battery @12V 7Ah.
  • Page 83 Installation and Programming Manual Violation of a zone with this configuration will not generate an alarm but will trigger the DELAYED EXIT ZONE associated Timer (refer to Exit time). For example, the zone that monitors the main door of a residence or building is usually configured as a delayed exit zone, in order to give occupants time to leave the partition after an arming operation.
  • Page 84 The Nexus dialer is a peripheral device which is completely SmartLiving-system-integrated and is managed through the control panel BUS. INIM's SmartLink is a similar device which is also compatible with control panels manufactured by other makers. This device is capable of providing the control panel with a telephone line even in the event of telephone line tamper (line cutting).
  • Page 85 Installation and Programming Manual If you wish to carry out maintenance work on the control without generating false alarms MAINTENANCE (tamper and intrusion), you must put the control panel in “Maintenance” mode. The control panel in must also be in “Maintenance” mode during the keypad and reader addressing process. The other functions of the control panel are still available (arm/disarm operations, events, calls, etc.).
  • Page 86 Installation and Programming Manual Pulse events are events which are a combination of other control panel events based on logical PROGRAMMABLE operations, counters and temporizers. EVENT For example, when it is necessary for more that one PIR detector to signal violation within a pre-set time in order to generate an alarm.
  • Page 87 Installation and Programming Manual The “supervision time” is the interval during which the wireless-system devices (in general SUPERVISION wireless detectors in permanent placements) must signal to the control panel that they are operating in the network. If a wireless device fails to signal before the “supervision time” expires, it will be classified as “Lost”...
  • Page 88 Installation and Programming Manual This device allows the control panel to send voice calls to programmed contact numbers. VOICE DIALER In SmartLiving control panels the voice dialer function is provided by the SmartLogos30M board (accessory item). If the system is equipped with a SmartLogos30M voice board, each JOY/MAX keypad, in the VOICE MEMO system configuration will allow users to record memos.

  • Page 89: Appendix B Shortcuts At Default

    Installation and Programming Manual Appendix B SHORTCUTS AT DEFAULT macro macro ICON description function parameter ICON description function num. num. ZoneBypass Accesses the User Menu Arm/Disarm Applies a pre-set scenario Scenario menu section: Activations/Zones Immediately deactivates the outputs relative to Accesses the User Menu Stop alarms zone/partition alarm and...

  • Page 90: Appendix C Available Icons

    Installation and Programming Manual Appendix C AVAILABLE ICONS The following table shows the icons provided at default. The icons can be customized to suit the keypad shortcuts. icon icon icon ICON ICON ICON number number number Available icons...

  • Page 91: Appendix D Voice Messages

    Installation and Programming Manual Appendix D VOICE MESSAGES The SmartLogos30M voice board provides 500 voice message slots, 291 of which are pre-recorded at factory. The messages are arranged in such way as to produce event-related voice calls which clearly describe the related event. The following Table shows the message numbers and their purpose, together with the respective recording time.
  • Page 92 Installation and Programming Manual Message duration (seconds) Message duration (seconds) Type Number Default message Type Number Default message Average Average High quality High quality quality quality Date/Time settings Key 1 Shortcuts Faults list Key 2 None available 232 - 240 ‘’...

  • Page 93: Appendix E Screw Terminals

    Installation and Programming Manual Appendix E SCREW TERMINALS All the terminals on the SmartLiving control panel and its peripherals (expansions and keypads) are identified by distinctive numbers transcribed in the “CCC” programming field of the “CONTACT-ID” protocol, in order to allow the precise localization of events related to zones or terminals.

  • Page 94: Appendix F Combination Of Outputs Triggered By Events

    Installation and Programming Manual Appendix F COMBINATION OF OUTPUTS TRIGGERED BY EVENTS This appendix shows the event-generated actions (activations/deactivations) of the outputs programmed in the “Outputs” and “Other outputs” sections combined with the “SirenSound types” of the sounderflashers on the BUS. Output typology Table 43: Symbol/Initials...

  • Page 95: Appendix G Compliancy With The Regulations In Force

    Installation and Programming Manual Appendix G COMPLIANCY WITH THE REGULATIONS IN FORCE In order to guarantee compliancy with the regulations in force, you must adhere to the following guidelines: • nBy/X readers must be equipped with devices which protect them against the forced-opening and dislodgement of their casings from their locations, in compliance with Level 2, as indicated in paragraph 3-2-5 Installing nBy/X readers.
  • Page 96 Installation and Programming Manual •• 50131StatHidden •• 50131IconsHidden •• 50131AlarDelayed •• 50131WarnLedMem • The following options must not be activated in the “Panel Options” section: •• ReaderBuzzer OFF •• BypassAlsoTamper • In the section “Other parameters - FaultNotReady”, enable the following options: ••...

  • Page 97: Appendix H Order Codes

    Intrusion control panel: manages 5 to 10 terminals, 5 partitions, switching power supply @ 1.2A, comes in metal SmartLiving515 enclosure with housing for 1 battery @7Ah SmartLogos30M Voice board (for SmartLiving) SmartLook SmartLook is a centralized-control programme for INIM's fire detection and intrusion control systems Order Codes...
  • Page 98 Installation and Programming Manual SmartModem100 Remote programming modem SPS12040 Switching power supply/battery charger in enclosure - 3A, 12V SPS12100 Switching power supply/battery charger in enclosure - 5A, 12V TamperNO Dislodgement-tamper device for SmartLiving control panels Order Codes...

  • Page 99: Notes

    Installation and Programming Manual Notes...
