7.8 Alarm relay 33
7.9 Fault relay 33
7.10 Connecting devices to the RS485 BUS 33
7.11 Connecting the SmartLoop/NET module 35
7.12 Connecting the SmartLoop/INOUT Board 35
7.13 Connecting to a PC 36
7.14 Connecting a SmartLAN (or SmartLAN/SF) equipped control panel to a PC 37
7.15 Connecting a serial printer 37
7.16 Batteries 37
7.17 Connecting the thermal probe 38
7.18 Connecting the mains power source 39
Chapter 8 Powering up the system ...................................................... 40
8.1 Testing wiring integrity 40
8.2 First power up 40
Chapter 9 Maintenance ...................................................................... 42
Chapter 10 Troubleshooting ................................................................. 43
10.1 Fault NAC, alarm or fault output trouble 43
10.2 LOOP fault 43
10.3 Fault on devices connected to the RS485 BUS 44
10.4 Battery Fault 44
10.5 SmartLoopNET Fault 44
Appendix A Enea devices...................................................................... 46
Appendix B Argus Devices .................................................................... 49
Appendix C Apollo Devices ................................................................... 53
Appendix D Order Codes ...................................................................... 57
Appendix D Notes: .............................................................................. 58
