Installing the Symantec Storage Shelf guide rails

Each left and right mounting rail for the Symantec Storage Shelf is shipped as a unit.
The front and back of each rail slide apart a few inches to allow for precise fitting into
the rack cabinet.
The bottom of each rail includes a sturdy metal ledge on which the Symantec Storage
Shelf sits.
Procedure
1.
2.
3.
4.
5.
6.
Wear an ESD-preventive wrist strap and ESD-preventive gloves.
Note: Locate the three heavy screws projecting from the left and right sides of the
NetBackup 5220. These three screws fit into the three slots in the rail extenders.
Using at least two people, lift the NetBackup 5220 and place it into the rail
extenders. Make sure that the rail slots securely fit the screws on the sides of the
device.
Gently slide the device into the rack.
If needed, install a front mounting plate to the front of the each rail, using a screw
to fasten it.
Repeat the previous steps to install a guide rail to the right side of the cabinet.
Obtain the left and right mounting rails. The front of these rails mount on the front
of the vertical metal posts of the rack cabinet.
Facing the rack cabinet, align the left rail over the vertical metal post on the left
side of the rack. Be sure that the support ledge is on the bottom of the rail, inside
the cabinet, so that the storage shelf can sit upon it.
Place the alignment pin in the top hole of the rail. Make sure it passes through the
rack and fasten the back of the pin.
Use a standard rack screw in the bottom hole of the rail, to secure the rail to the
rack.
Slide the rear of the mounting rail into the rear metal post of the rack.
Repeat these steps for the mounting rail on the right side of the rack, again be sure
that the support ledge is on the bottom of the rail, inside the cabinet.
