Installing the Symantec Storage Shelf guide rails

To remove the protective film
Warning: Make sure that another person is available to help lift the storage shelf.
1
Peel the protective film from the top of the storage shelf.
2 Lift up one end of the storage shelf and peel the film from the bottom of the
chassis.
3 When approximately half of the film is removed, lift the other end of the storage
shelf and remove the remaining film.
4 Peel the film from the sides of the storage shelf.
5
Discard all of the film.
See "Installing the Symantec Storage Shelf guide rails"
The Symantec Storage Shelf is shipped with left and right mounting rails. These
rails install in a standard 19-inch rack. The front plates of the rails are marked left
and right. Two-inch lips on the bottoms of the rails provide a shelf on which the
storage system sits. Extenders that are built into the rails let you adjust the rails for
the depth of the rack.
Caution: Due to the weight of the units, Symantec recommends that storage shelves
be installed at or near the bottom of the rack.
Requirements
19-inch equipment rack
■
Available 3U slot
■
Six M5 screws (provided)
■
Six cage nuts (provided)
■
Number 2 Phillips screwdriver
■
Flashlight
■
Installing hardware into racks
Installing the Symantec Storage Shelf guide rails
on page 33.
