Installing the Symantec Storage Shelf guide rails

The Symantec Storage Shelf is shipped with left and right mounting rails. These
rails install in a standard 19-inch rack. The front plates of the rails are marked
left and right. Two-inch lips on the bottoms of the rails provide a shelf on which
the storage system sits. Extenders that are built into the rails let you adjust the
rails for the depth of the rack.
Caution: Due to the weight of the units, Symantec recommends that storage shelves
be installed at or near the bottom of the rack.
Requirements
19-inch equipment rack
Available 3U slot
Six M5 screws (provided)
Six cage nuts (provided)
Number 2 Phillips screwdriver
Flashlight
