38 Chapter 4
Installation requirements

Power supply requirements

Power supply requirements
This section describes the requirements of the NetBackup 5220 on the power supply.
Before installing the device, check whether the power supply satisfies the conditions for
proper running of the device.

Power values

Power values

Power supplies

The NetBackup 5220 and the Symantec Storage Shelf each have two power modules,
which connect to the main AC power source such as a wall outlet. Both modules, on both
devices, provide redundant power in case of failure.

Power cable and power socket

Dual power cords (one per power module) are supplied. This enables you to connect
each power cord to an independent AC power source.
If multiple NetBackup 5220s are to be installed on site, check whether the power
distribution in your equipment room satisfies the requirements according to the
maximum input power and quantity of devices.
Component SubComponent
Power Maximum power
consumption consumption
Power AC voltage range
parameters
AC frequency range
Base System Storage Shelf
750 W 580 W
100 V to 127 V 200 V to 240 V
47 Hz to 63 Hz 47 Hz to 63 Hz
