Risk of accident during vehicle operation if the mounting of the DLT-V4108 becomes
loose and breaks while driving.
Ensure the following when attaching the mounting on the VESA mounting hole pattern:
−
Specialty mechanical knowledge is required for correct mounting!
−
Use suitable fastening materials.
−
Use suitable screws: Screws that are too long can penetrate the back of the vehicle
docking station and cause irreparable damage. Screws that are too short do not provide
secure mounting.
−
Use suitable washers.
−
Observe the maximum screw-in depth of the hole of the mounting hole pattern:
The recommended screw-in depth of Dx1 always applies (screw diameter x 1).
−
Advantech-DLoG mountings include suitable screws and washers. Please use them.
Examples for RAM Mount Set mounting materials
RAM Mount Set short (arm length, 130 mm)
Advantech-DLoG order no:
DL-CMEMT70129800
Fixing plate RAM-Mount VESA
RAM conn. arm VESA 130mm
Washer spring A6 DIN128 FSt galvan.
Screw Cyl.int.hex DIN912 M6x16 V2A
Washer ISO 8738 (DIN 1440)-A6-A2
56 / 81
WARNING
DLT-V4108 Manual, V01 Prelim
RAM Mount Set long (arm length 215 mm)
Advantech-DLoG order no:
DL-CMEMT70129700
Fixing plate RAM-Mount VESA w.ball 2.25"
Holder VESA connect.arm 215mm ball 2.25"
Screw Cyl.int.hex DIN912 M6x16 V2A
Washer ISO 8738 (DIN 1440)-A6-A2
Washer spring A6 DIN128 FSt galvan.
