Operating the DLT-V4108
7.5.

DLT-V4108 front keys

Left side of the device:
Key
Right side of the device:
Key
Advantech-DLoG
Explanation
<Power> button, switch device on/off:
To do this, press and hold the button for 2 seconds
After the device has been switched off, it can only be switched on
again after 10 seconds.
Manual brightness control: Display brighter
Manual brightness control: Display darker
Switch the backlight on/off
NOTE: The DLT-V4108 will continue to react to keyboard, mouse
and touchscreen inputs even if the backlight is switched off.
Activate/deactivate touchscreen.
LED on: Touchscreen inactive
LED off: Touchscreen active
Switch special keys S1 up to S6 to assignment S2 up to S12;
Shift is activated when the LED lights up.
Explanation
Special keys S1 to S12; these keys are configured with the
"MDevice" program; the associated manual is available in the
Download Center at: www.advantech-dlog.com.
DLT-V4108 Manual, V01 Prelim 21 / 81
