To disarm the System using a smartkey (if supported):
Place a registered smartkey against the center of the smartkey reader
of the Wireless Terminal – see p. 14 2.6 Wireless Terminal Smartkey
(Model Dependant) . When the smartkey is read, the keypad will sound
a beep – the system is disarmed.
Wireless Terminal EL‐2724 does not support partitioning.
3.6. Arm Status and Other System Status
Indication
The following table explains the various arm status descriptions
as they appear on the LCD display.
Unpartitioned Systems
Status
DISARMED
FULL ARMED
PART ARMED
PERIMETER ARMED
PART ARMED INST
PERIM ARMED INST
FULL ARMING
PART ARMING
PERIMETER ARMING
PART ARMING INST
PERI ARMING INST
Partitioned Systems
Status
DISARMED
SYSTEM ARMED
PART 1 ARMED
PART 2 ARMED
SYSTEM ARMING
PART 1 ARMING
PART 2 ARMING
20
Meaning
The system is disarmed.
The system has been armed using the displayed arming
method.
The system is in the process of arming using the
displayed arming method (displayed during exit delay).
Meaning
The system is disarmed.
The system has been armed.
Partition 1/partition 2 has been armed.
The system is in the process of arming
Partition 1/partition 2 is in the process of arming.
3. Arming and Disarming
DISARMED
11:22:02
