2. The User Interface
!
LED Status
(Yellow)
Off
On
Flashing
(slow)
Flashing (fast)
Flashing
(intermittent)
,
Off
Flashing Red
On Green
All the three Arm Status
LEDs flash Red
2.3.

Alarm Sounding Patterns

The following table summarizes various alarms sounded by the control system.
Alarm
Burglary
Fire
Gas
Medical
Flood
Environmental
iConnect User Manual
Meaning
No trouble condition in the system.
System Trouble.
Backup battery low or low battery from transmitters.
AC loss.
System Trouble in addition to AC loss/Low Battery.
& LEDs
Alarm Sounding Pattern Description
ON (continuously)
ON - ON - ON, 1.5-second pause, ON - ON – ON......
ON - ON - ON - ON (short bursts), 5 second pause, ON - ON -
ON - ON......
ON (continuously) – only applicable for Medical alarm from zone
4 rapid tones sounded once per minute (same as Trouble tones)
4 rapid tones sounded once per minute (same as Trouble tones)
Meaning
The corresponding arming method is not active.
In partitioned systems, the corresponding
partition is disarmed. If all the three LEDs are
off, the system is disarmed.
The exit or entry delay for this arming mode is
counting down.
The System is armed using the arming method
shown by this LED. In partitioned systems, the
corresponding partition/whole system is armed.
An alarm has occurred. Alarm indication is
cleared the next time you arm the system or
view the relevant event in the event log.
