Service Call Button
The Service Call button enables you to contact the monitoring service and talk
to an operator.
To initiate a service call, press the up arrow button
Service Call button
Speed Dial
The Speed Dial feature enables you to call from the control system up to five different
telephone numbers programmed in the system – see p. 34, 7.5 Speed Dial Numbers .
To dial one of the programmed Speed Dial numbers, press the up arrow button
then press and hold down the number button 1 to 5 until ʺCall Spd # Dialingʺ is
displayed. When finished speaking, press the button to disconnect.
Vocal Message Recording and Playback
LCD front panel allows you to record a short message that may be played back later by
another user – see p. 35, 7.7. Service Menu, Message Center.
Home Automation and PGM On/Off Buttons
Pressing one of the Home Automation buttons followed by the
unit number (01‐16, or 30 for PGM) enables you to control
lights and appliances in your home, activate and deactivate
PGM output.
Pressing both Home Automation buttons simultaneously
generates an SOS panic alarm.
System Status LEDs
The System Status indicators provide essential information on the status of the system
such as arm, disarm, alarm and power failure conditions.
OK
LED Status
Off
On Green
Flashing Green
On Yellow
Flashing Yellow (slow)
Flashing Yellow (fast)
Flashing Yellow
(intermittent)
6
.
Meaning
Both AC and Battery power are disconnected.
System Power status is OK and there is no System Trouble.
Open Zone. Check that the windows and doors are closed
and no movement is detected by the sensors within the
protected area.
System Trouble.
Battery low from the Control System or transmitters.
AC loss.
System Trouble in addition to AC loss/Low Battery.
, then press and hold down the
2. The User Interface
