Figure 6-9 Installing the compute module
Install the removed security bezel. For more information, see
6.
Connect the power cord. For more information, see
7.
Power on the server. For more information, see
8.
Verifying the installation
Log in to HDM to verify that the compute module is operating correctly. For more information, see
HDM online help.

Installing air baffles

For more information about air baffles available for the server, see "Air baffles."
Installing the low mid air baffle or GPU module air baffle to a
compute module
Power off the server. For more information, see
1.
Remove the security bezel, if any. For more information, see
2.
Remove the compute module. For more information, see
3.
Remove the compute module access panel. For more information, see
4.
module access
Remove the high mid air baffle. For more information, see
5.
module."
Install the low mid air baffle or GPU module air baffle.
6.
To install the low mid air baffle, align the two pin holes with the guide pins on the processor
socket and the cable clamp. Then, gently press down the air baffle onto the main board of
the compute module, as shown in
panel."
"Connecting the power
"Powering on the
"Powering off the
"Removing a compute
"Replacing air baffles in a compute
Figure 6-10.
6-7
"Installing the security
cord."
server."
server."
"Replacing the security
module."
"Replacing a compute
bezel."
bezel."
