H3C UniServer R6900 G3 User Manual page 130

To replace the left chassis ear:
Power off the server. For more information, see
1.
Remove the server from the rack, if the space over the server is insufficient. For more
2.
information, see
Remove the security bezel, if any. For more information, see
3.
Remove compute modules. For more information, see
4.
Remove the chassis access panel. For more information, see
5.
panel."
Remove the power supply air baffle. For more information, see
6.
baffle."
Disconnect the front VGA and USB 2.0 cable from the PDB, and pull the cable out of the cable
7.
cutout as shown in
Figure 7-57 Removing the front VGA and USB 2.0 cable
Remove the screws that secure the left chassis ear, and then pull the chassis ear until it is
8.
removed, as shown in
"Removing the server from a
Figure 7-57.
Figure 7-58.
7-49
"Powering off the server."
rack."
"Replacing the security
"Removing a compute
"Replacing the chassis access
"Replacing the power supply air
bezel."
module."
