Figure 10-5 16SFF front panel
(1) Serial label pull tab module
(3) VGA connector
(5) Compute module 1
(7) SAS/SATA drive, NVMe drive, or diagnostic panel (optional)
(8) USB 3.0 connector
(10) Compute module 2
Front panel view of a compute module
Figure 10-6
respectively.
Figure 10-6 24SFF compute module front panel
(1) 24SFF SAS/SATA drives
and
Figure 10-7
show the front panel views of 24SFF and 8SFF compute modules,
(2) USB 2.0 connectors
(4) Drive cage bay 1
(6) Drive cage bay 2
(9) Drive cage bay 4
(11) Drive cage bay 3
(2) Diagnostic panel (optional)
10-6
