Replacing an mLOM Ethernet adapter

The procedure is the same for mLOM Ethernet adapters of different models. This section uses the
NIC-GE-4P-360T-L3-M mLOM Ethernet adapter as an example.
Procedure
Power off the server. For more information, see
1.
Disconnect external cables from the riser card that holds the mLOM Ethernet adapter.
2.
Remove the riser card. For more information, see
3.
the server
Remove the mLOM Ethernet adapter, as shown in
4.
a. Open the riser card cover. For more information, see
modules at the server
b. Remove the screw that secures the mLOM Ethernet adapter, and then pull the Ethernet
adapter out of the slot, as shown in
Figure 7-30 Removing an mLOM Ethernet adapter
Install a new mLOM Ethernet adapter. For more information, see
5.
adapter."
Install the riser card. For more information, see
6.
server
rear."
rear."
rear."
"Powering off the
"Replacing a riser card and PCIe module at
Figure 7-30:
"Installing riser cards and PCIe
Figure 7-30.
"Installing riser cards and PCIe modules at the
7-25
server."
"Installing an mLOM Ethernet
