Figure 7-42 Smearing thermal grease onto the processor
Install the retaining bracket onto the heatsink. For more information, see
3.
Install the heatsink onto the server. For more information, see
4.
Paste bar code label supplied with the processor over the original processor label on the
5.
heatsink.
IMPORTANT:
This step is required for you to obtain H3C's processor servicing.
Install the removed air baffles in the compute module. For more information, see
6.
baffles in a compute
Install the removed riser card and PCIe module in the compute module. For more information,
7.
see "Installing a riser card and a PCIe module in a compute
Install the compute module access panel. For more information, see
8.
module access
Install the compute module. For more information, see
9.
10. Install the removed security bezel. For more information, see
11. Connect the power cord. For more information, see
12. Power on the server. For more information, see

Verifying the replacement

Log in to HDM to verify that the processor is in a correct state. For more information, see HDM online
help.

Replacing a DIMM

WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
Procedure
Power off the server. For more information, see
1.
module."
panel."
"Installing a compute
"Connecting the power
"Powering on the
"Powering off the
7-37
"Installing processors."
"Installing processors."
"Replacing air
module."
"Replacing a compute
module."
"Installing the security
cord."
server."
server."
bezel."
