LED Error code
A1 through A9,
AA, Ab, or AC
b1 through b9,
bA, bb, or bC
DIMM
C1 through C9,
CA, Cb, or CC
d1 through d9,
dA, db, or dC
00 through 23
30 through 53
HDD
00 through 07
10 through 17
01
03
11 through 16
PCIE
21 through 26
31 through 36
09
01
02
PSU
03
04
FAN 01 through 06
Faulty item
Compute module 1:
•
A1 through A9—DIMMs in slots A1 through A9
•
AA—DIMM in slot A10
•
Ab—DIMM in slot A11
•
AC—DIMM in slot A12
Compute module 1:
•
b1 through b9—DIMMs in slots B1 through B9
•
bA—DIMM in slot B10
•
bb—DIMM in slot B11
•
bC—DIMM in slot B12
Compute module 2:
•
C1 through C9—DIMMs in slots A1 through A9
•
CA—DIMM in slot A10
•
Cb—DIMM in slot A11
•
CC—DIMM in slot A12
Compute module 2:
•
d1 through d9—DIMMs in slots B1 through B9
•
dA—DIMM in slot B10
•
db—DIMM in slot B11
•
dC—DIMM in slot B12
Relevant drive in compute module 1 (24SFF)
Relevant drive in compute module 2 (24SFF)
Relevant drive in compute module 1 (8SFF)
Relevant drive in compute module 2 (8SFF)
PCIe module in PCIe slot 1 of riser card 0 in compute module 1
PCIe module in PCIe slot 1 of riser card 0 in compute module 2
PCIe modules in PCIe slots 1 through 6 of riser card 1 at server rear
PCIe modules in PCIe slots 1 through 6 of riser card 2 at server rear
PCIe modules in PCIe slots 1 through 6 of riser card 3 at server rear
PCIe uplink between processors and the PCH for the mLOM Ethernet
adapter
Power supply 1
Power supply 2
Power supply 3
Power supply 4
Fan module 1 through Fan module 6
