Figure 7-20 Installing a riser card air baffle
Install the riser card. For more information, see
6.
server
Reconnect the external cables to the riser card.
7.
Connect the power cord. For more information, see
8.
Power on the server. For more information, see
9.

Replacing a riser card and a PCIe module

WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
Replacing the riser card and PCIe module in a compute
module
Power off the server. For more information, see
1.
Remove the security bezel, if any. For more information, see
2.
Remove the compute module. For more information, see
3.
Remove the compute module access panel. For more information, see
4.
module access
Remove the riser card in the compute module:
5.
rear."
panel."
"Installing riser cards and PCIe modules at the
"Connecting the power
"Powering on the
"Powering off the
"Removing a compute
7-16
cord."
server."
server."
"Replacing the security
module."
"Replacing a compute
bezel."
