Product
code
0231AC4S
0231AC4V
0231AC4T
0231AC4N

DCPMM specifications

Product code
0231AC5R
0231AC7P
0231AC65

DRAM DIMM rank classification label

A DIMM rank is a set of memory chips that the system accesses while writing or reading from the
memory. On a multi-rank DIMM, only one rank is accessible at a time.
To determine the rank classification of a DRAM DIMM, use the label attached to the DIMM, as shown
in Figure 11-1.
Figure 11-1 DRAM DIMM rank classification label
Table 11-3 DIMM rank classification label description
Callout
1
2
3
Model
DDR4-2933P-16G-1Rx4-R
DDR4-2933P-16G-2Rx8-R
DDR4-2933P-32G-2Rx4-R
DDR4-2933P-64G-2Rx4-R
Model
AP-128G-NMA1XBD128GQSE
AP-256G-NMA1XBD256GQSE
AP-512G-NMA1XBD512GQSE
Description
Capacity
Number of ranks
Data width
Type Capacity
RDIMM 16 GB
RDIMM 16 GB
RDIMM 32 GB
RDIMM 64 GB
Type
Apache Pass
Apache Pass
Apache Pass
Remarks
•
8GB.
•
16GB.
•
32GB.
•
1R— One rank.
•
2R—Two ranks.
•
4R—Four ranks.
•
8R—Eight ranks.
•
×4—4 bits.
•
×8—8 bits.
11-4
Data rate Rank
2933 MHz Single-rank
2933 MHz Dual-rank
2933 MHz Dual-rank
2933 MHz Dual-rank
Capacity Data rate
128 GB 2666 MHz
256 GB 2666 MHz
512 GB 2666 MHz
