DRAM specifications

Product code
0231AADX
0231AADY
0231A6SR
0231A6SP
0231A6SQ
0231AADP
0231AAEF
0231AAEG
0231AAEH
0231AAE8
0231AAE0
0231A6SS
0231AAE9
0231AAEJ
0231AAEK
0231A8QJ
0231AADQ
0231AADT
0231AADR
0231AC4S
0231AC4V
0231AC4T
0231AC4N

DCPMM specifications

Product code
0231AC5R
0231AC7P
0231AC65

DIMM rank classification label

A DIMM rank is a set of memory chips that the system accesses while writing or reading from the
memory. On a multi-rank DIMM, only one rank is accessible at a time.
Model
DDR4-16G-1Rx4-R-1
DDR4-32G-2Rx4-R-1
DDR4-2666-8G-1Rx8-R
DDR4-2666-16G-1Rx4-R
DDR4-2666-16G-2Rx8-R
DDR4-2666-16G-1Rx4-R-1
DDR4-2666-16G-1Rx4-R-2
DDR4-2666-16G-1Rx4-R-3
DDR4-2666-16G-2Rx8-R-1
DDR4-2666-16G-2Rx8-R-2
DDR4-2666-16G-2Rx8-R-3
DDR4-2666-32G-2Rx4-R
DDR4-2666-32G-2Rx4-R-1
DDR4-2666-32G-2Rx4-R-2
DDR4-2666-32G-2Rx4-R-3
DDR4-2666-64G-4Rx4-L
DDR4-2666-64G-4Rx4-L-1
DDR4-2666-64G-4Rx4-L-2
DDR4-2666-64G-4Rx4-L-3
DDR4-2933P-16G-1Rx4-R
DDR4-2933P-16G-2Rx8-R
DDR4-2933P-32G-2Rx4-R
DDR4-2933P-64G-2Rx4-R
Model
AP-128G-NMA1XBD128GQSE
AP-256G-NMA1XBD256GQSE
AP-512G-NMA1XBD512GQSE
Type Capacity
RDIMM 16 G
RDIMM 32 G
RDIMM 8 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 32 GB
RDIMM 32 GB
RDIMM 32 GB
RDIMM 32 GB
LRDIMM 64 GB
LRDIMM 64 GB
LRDIMM 64 GB
LRDIMM 64 GB
RDIMM 16 GB
RDIMM 16 GB
RDIMM 32 GB
RDIMM 64 GB
Type
Apache Pass
Apache Pass
Apache Pass
16
Data rate Rank
2400 MHz Single-rank
2400 MHz Dual-rank
2666 MHz Single-rank
2666 MHz Single-rank
2666 MHz Dual-rank
2666 MHz Single-rank
2666 MHz Single-rank
2666 MHz Single-rank
2666 MHz Dual-rank
2666 MHz Dual-rank
2666 MHz Dual-rank
2666 MHz Dual-rank
2666 MHz Dual-rank
2666 MHz Dual-rank
2666 MHz Dual-rank
2666 MHz Quad-rank
2666 MHz Quad-rank
2666 MHz Quad-rank
2666 MHz Quad-rank
2933 MHz Single-rank
2933 MHz Dual-rank
2933 MHz Dual-rank
2933 MHz Dual-rank
Capacity Data rate
128 GB 2666 MHz
256 GB 2666 MHz
512 GB 2666 MHz
